LUBRICATION

Steering and Suspension

Lube Point
Item
Description
Steer Cylinder
1
Pivot Pins
Upper and Lower
2
King Pins
Fifth Wheel
3
Pivots
Lockout Cylinder
4
Pivot Pins
5-6
Figure Approved
No. Lubricant
EP-MPG
Extreme
Pressure
Figure 5-1
Multipurpose
Grease
6829003477
EP-MPG
Extreme
Pressure
Figure 5-1
Multipurpose
Grease
6829003477
EP-MPG
Extreme
Pressure
Figure 5-1
Multipurpose
Grease
6829003477
EP-MPG
Extreme
Pressure
Figure 5-1
Multipurpose
Grease
6829003477
Published 5-3-2016, Control # 555-02
RT530E-2 OPERATOR'S MANUAL
Crushing Hazard!
Movement of the superstructure and the boom may
create a crushing and/or pinching hazard. Failure to
observe this warning could result in death or serious
injury.
Lube
Lube Interval
Capacity
Until
grease 500 hours or 3 months
extrudes
Until
grease 500 hours or 3 months
extrudes
Until
grease 500 hours or 3 months
extrudes
Until
grease 500 hours or 3 months
extrudes
DANGER
Application
8 grease fittings
8 grease fittings
2 grease fittings
4 grease fittings
