6. Slide the bracket, now containing the CD drive, halfway into the CD
drive bay.
7. Connect the power, audio, and ribbon cables into their respective
connectors, taking care to fold the ribbon cable neatly, so it won't be
crushed during insertion.
8. Finish seating the CD drive bracket into the main chassis, taking
care not to pinch the cables as the CD drive is being pushed into the
bay. Insert the two screws through the front of the tray to secure the
assembly to the main chassis.
9. Replace the CD EMI cover, again taking care not to pinch the cables.
10. Replace the computer's top panel and front panel.
11. After rebooting, use SAM (the System Administration Manager), or
the steps in the next section, to confirm that the CD drive is
recognized by the system.
For information on normal usage, see the chapter "Using Your CD Drive."
