Reinstalling the Cover Panels

To replace the cover panels once you've taken them off, perform the
following steps:
1. Place the left- and right-side panels into their grooves in the bottom
edges of the left and right sides of the chassis, and then press the tops
of the side panels together firmly.
2. Place the top cover on the top of the chassis, about an inch of its back
edge protruding over the rear panel. Then, push it straight forward,
so its front edge slides underneath the lip of the front panel's top
edge. The top panel fits snugly, so you may have to get a firm grip on
it in order to slide it forward.
3. Reinsert the two thumbscrews into the tabs in the upper corners of
the back panel of the chassis. Note that the upper left one (as looking
at the rear panel) is the power supply interlock screw, so make sure it
is tightened snugly, or the power supply may not engage.
