Cd Drive Installation - HP Visualize J5000 Owner's Manual

Changing Your Computer's Hardware Configuration

CD Drive Installation

CD Drive Installation
To install a CD drive, follow the steps below:
1. Using standard static-suppression practices (described in the Preface
Figure 2-14 Removing the CD Drive Bay's EMI Cover
CD drive bay's
EMI cover
2. Remove the CD drive bracket from the main chassis.
3. Remove the filler panel from the bracket and save it for future use.
58
of this document), remove the computer's front panel, as described
in"Removing the Front Panel" on page 42, and top cover, as described
in "Opening the Top Cover" on page 44. Then lift out the CD bay's
EMI (electromagnetic interference) cover—the thin piece of metal
above the CD drive bay, that is held in place by metal tabs along its
edge:
The screws will be used the mount the CD drive into the bracket.
Chapter 2
