System Board Removal/Replacement

Removing the Power Supply

Removing the Power Supply
1. Position the workstation on its side so the power supply label is facing
2. Position the conductive sheeting so that an inch of one edge is under
Figure 2-3 Power Supply Screws and Handles
T15 Torx
Thumbscrew
3. Alternately loosen the two T-15 Torx screws from the corners of the
4. Using the handle, lift up the power supply and place the bail in the
20
you. It is best to use a cushioned surface to protect the exterior of the
system from damage.
the workstation and the rest is flat against the work area to lay
system components on after you remove them. Also ensure that your
static-grounding strap is securely attached to your wrist and to bare
metal on the workstation.
power supply as shown above.
bail lock to hold the power supply upright.
Power Supply
Handle
T15 Torx
Thumbscrew
Chapter 2
