3. Grasp the system-board tray handle and slide the system board tray
toward the front of the workstation to unseat the keyhole standoffs on
the floor of the chassis, underneath the board. Using the handle, lift
the system board tray out of the workstation and place it on the
conductive sheeting.

Installing the new System Board

1. Position the system board tray in the new chassis. When it is flat in
the workstation, align the system board tray's keyholes with the
standoffs on the side wall of the chassis, and then slide the system
board tray toward the back of the workstation to seat the standoffs
into their corresponding keyholes.
2. Replace the two T-15 Torx screws that secure the system board tray to
the rear wall of the workstation.
3. Place the old system board tray into the protective packaging from
the new replacement system board and put it aside.
Chapter 2
System Board Removal/Replacement
Removing and Replacing the System Board
31
