HP Visualize c3600 Upgrade Instructions

Unix workstation
Hide thumbs Also See for Visualize c3600:

Advertisement

®
HP V
C3600 UNIX
Workstations
ISUALIZE
PA8600
Upgrade Instructions
Manufacturing Part Number: A5997-90000
Edition E1299
© Copyright 1999 by Hewlett-Packard

Advertisement

Table of Contents
loading

Summary of Contents for HP Visualize c3600

  • Page 1 ® HP V C3600 UNIX Workstations ISUALIZE PA8600 Upgrade Instructions Manufacturing Part Number: A5997-90000 Edition E1299 © Copyright 1999 by Hewlett-Packard...
  • Page 2: Hewlett-Packard Warranty Statement

    Hewlett-Packard Company. Hewlett-Packard Warranty Statement Refer to Warranty & Support for your HP Workstation for warranty terms applicable to your Hewlett-Packard product and replacement parts. Restricted Rights Legend Use, duplication, or disclosure by the U.S.
  • Page 3 UNIX is a registered trademark in the United States of America and other countries, licensed exclusively through X/Open Company Limited. © Copyright 1980, 1984 AT&T, Inc. © Copyright 1979, 1980, 1983 The Regents of the University of California. This software and documentation is based in part on the Fourth Berkeley Software Distribution under license from the Regents of University of California.
  • Page 5: Getting Started

    Getting Started The following important information must be adhered to for proper removal and replacement of all Hewlett-Packard parts.
  • Page 6 Getting Started CAUTION This upgrade process should be performed by experienced hardware users only. Chapter 1...
  • Page 7: Safety Warnings

    flat, stable surface, such as a table top or workbench. NOTE Installing the recommended HP replacement part in your B1000/C3000 workstation does not affect the regulatory and safety classifications or approvals listed in the original owner’s guide.
  • Page 8 Getting Started Safety Warnings strap, clips attached to the wrist strap, nodes, and peripheral units. • Keep uninstalled printed circuit boards in their protective antistatic bags. • Once you have removed printed circuit boards from their protective antistatic bags, handle the printed circuit boards by their edges only. Chapter 1...
  • Page 9: Replacement Part Kit Contents

    Getting Started Replacement Part Kit Contents Replacement Part Kit Contents Take a moment to verify that your kit contains the following contents: • System board upgrad tray assembly • Electrostatic Discharge (ESD) materials • Removal/Replacement Instructions If you are missing any part or any documentation, please call your designated service representative.
  • Page 10: Required Tools

    Getting Started Required Tools Required Tools You will need the following tools for removal/replacement procedures: • T-10 and/or T-15 Torque drivers • ESD materials • Sufficient ESD protected surfaces on which to lay out parts Chapter 1...
  • Page 11 B1000/C3000 to a C3600. 1. Prepare your workstation - Verify that you have the correct version of HP-UX. - Determine and WRITE DOWN the LAN ID of your system. You may need to re-enter it in the new system - Power off the workstation and any peripherals.
  • Page 12: Preparing Your Workstation

    Getting Started Preparing Your Workstation Preparing Your Workstation The workstation must be running HP-UX 10.20 or later with Additional Core Enhancements (ACE4) 9906 to accommodate the PA8600 upgrade. Use the command uname -r to determine the revision of your operating system.
  • Page 13 Safely Powering Down the B1000/C3000 Workstation You must complete the following steps before performing any of the removal and replacement procedures: CAUTION Do not use the power supply interlock to power down the workstation. This power down method may hang the operating system in an unrecoverable state.
  • Page 14: Product Exploded Diagram

    Getting Started Product Exploded Diagram Product Exploded Diagram Refer to the figure below for a basic parts overview of the B1000/C3000 workstation. Figure 1-1 Exploded View I/O Fan/Speaker Bracket stem-Board Fans Speaker I/O Card Retainer Clip Air Divider Power Supply Side Panel I/O Fan System Board...
  • Page 15 Getting Started Product Exploded Diagram Chapter 1...
  • Page 16 Getting Started Product Exploded Diagram Chapter 1...
  • Page 17 System Board Removal/Replacement This chapter describes how to remove and replace the System Board for the B1000/C3000 workstation.
  • Page 18: Removing The Terminators And Cables

    System Board Removal/Replacement Removing the Terminators and Cables Removing the Terminators and Cables 1. After powering down the workstation as described in the “Getting Started” chapter, unplug the power cable from the back of the workstation. To avoid ESD damage to components, carefully follow the ESD procedures (also described in the “Getting Started”...
  • Page 19: Removing The Side Panel

    Removing the Side Panel 1. Remove the two T-15 Torx thumbscrews located in the top and bottom right edge of the back side of the workstation, as shown below. Figure 2-2 Opened Side Panel Side-Panel Thumbscrew 2. Remove the left side panel by grasping the back edge of the panel and rotating the panel outward as shown above.
  • Page 20: Removing The Power Supply

    System Board Removal/Replacement Removing the Power Supply Removing the Power Supply 1. Position the workstation on its side so the power supply label is facing you. It is best to use a cushioned surface to protect the exterior of the system from damage.
  • Page 21 Figure 2-4 Tipping Up the Power Supply Spring Hinge Bail Lock Bail 5. Disconnect the four cables shown below located below the raised power supply: three system power cables and the SCA hard disk backplane cable. Figure 2-5 Location of Power Cables 6.
  • Page 22 System Board Removal/Replacement Removing the Power Supply lock (see Figure 2-4 on page 21). b. Slide the spring hinge lever toward the front of the workstation and rotate it downward to lock it in place (see Figure 2-4 on page 21).
  • Page 23 Removing the Hard Disk Fan 1. Locate the memory DIMMs. The hard disk fan is to the right of these. 2. Disconnect the power cable from the system board that drives the hard-disk fan. Figure 2-6 Removing the Hard Disk Fan Fan Power Cable DIMMs 3.
  • Page 24: Removing The Memory Cards (Dimms)

    System Board Removal/Replacement Removing the Memory Cards (DIMMs) Removing the Memory Cards (DIMMs) 1. Press downward on the ejector tabs located on each side of the memory card (DIMM) slot. Figure 2-7 Removing a DIMM 2. Grasp the memory card by its edges and lift it straight out. Place the card on the conductive sheeting.
  • Page 25: Removing The Air Divider

    Removing the Air Divider 1. Remove the PCI retainer clip by pulling evenly in the direction of the “Pull” tabs on the clip and lifting it out of the workstation. Figure 2-8 Removing the Air Divider 2. Remove the two T-15 Torx screws that secure the air divider to the chassis.
  • Page 26 System Board Removal/Replacement Removing the PCI I/O Card(s) Removing the PCI I/O Card(s) CAUTION When removing a PCI I/O card, do not rock it from side to side, or the card may be damaged. After removing each I/O card, locate the label which indicates the PCI installation sequence, and place it on the conductive sheeting until needed for re-assembly.
  • Page 27 System Board Removal/Replacement Removing the PCI I/O Card(s) Figure 2-10 Removing the PCI Cards 3. Repeat Steps 1 and 2 above to remove all the PCI I/O cards. Chapter 2...
  • Page 28: Disconnecting The Cables

    System Board Removal/Replacement Disconnecting the Cables Disconnecting the Cables 1. Disconnect the following nine cables from the system board: • Fan cables for top and bottom system-board fans and I/O fan • Power cable for CD drive • Data cables for CD drive and floppy drive •...
  • Page 29 Figure 2-11 Cable locations Drive ta Connector p Sys. Board Fan wer Connector ppy Drive ta Connector ttom Sys. Board Fan wer Connector ra 2 Wide LVD SI Connector 2. Inspect the system board to ensure that all cables are disconnected. NOTE The DIMMs are shown for orientation purposes.
  • Page 30: Removing And Replacing The System Board

    System Board Removal/Replacement Removing and Replacing the System Board Removing and Replacing the System Board WARNING To avoid system damage, make sure your static-grounding strap is securely attached to your wrist and to the bare metal on the workstation. Removing the old System Board 1.
  • Page 31: Installing The New System Board

    3. Grasp the system-board tray handle and slide the system board tray toward the front of the workstation to unseat the keyhole standoffs on the floor of the chassis, underneath the board. Using the handle, lift the system board tray out of the workstation and place it on the conductive sheeting.
  • Page 32: Reconnecting Cables

    System Board Removal/Replacement Reconnecting Cables Reconnecting Cables 1. Connect the following nine cables to their respective connectors on the system board (which, for clarity, is again shown outside the chassis): • Fan cables for top and bottom system-board fans and I/O fan •...
  • Page 33 Figure 2-13 Connecting the Cables Drive ta Connector p Sys. Board Fan wer Connector ppy Drive ta Connector ttom Sys. Board Fan wer Connector ra 2 Wide LVD SI Connector 2. Inspect the system board to ensure that all cables are connected (all cables, except the fan cables, are unique and fit only one connector) and securely seated—loose connections may result in poor system performance.
  • Page 34 System Board Removal/Replacement Reinserting PCI I/O Cards Reinserting PCI I/O Cards NOTE Reference the PCI label in the system for correct installation procedure. CAUTION When installing a PCI I/O card, do not rock it from side to side, or the card may be damaged.
  • Page 35 Figure 2-15 Inserting the PCI Cards’ Bulkhead Screws 3. Repeat Steps 1 and 2 above to install all the PCI I/O cards. Chapter 2 System Board Removal/Replacement Reinserting PCI I/O Cards Bulkhead screws (insert from inside) Typical PCI Card...
  • Page 36 System Board Removal/Replacement Reinstalling the Air Divider Reinstalling the Air Divider 1. Slide the air divider into the workstation. 2. Replace the two T-15 Torx screws—one on the back and one on the side—that secure the air divider to the chassis. 3.
  • Page 37 Reinserting the Memory Cards (DIMMs) 1. Make sure the ejector tabs are angled outward. Next, align the notched edge of the memory card with its slot. Insert the memory card and firmly and evenly push down on each side to lock it into place.
  • Page 38 System Board Removal/Replacement Reinstalling the Hard Disk Fan Reinstalling the Hard Disk Fan 1. Locate the area next to the DIMMs from which the fan was removed. 2. Align the hard-disk fan with the fan bracket guide and slide it into place, making sure the tabs engage the holes in the chassis.
  • Page 39: Reinstalling The Power Supply

    Reinstalling the Power Supply 1. To install the power supply: a. Pick up the power supply by the handle and position its right-side b. Align the shaft of the spring hinge (on the left side) with its hole in c. Reconnect the power supply to the bail lock. Figure 2-19 Reinstalling the Power Supply Spring Hinge...
  • Page 40 System Board Removal/Replacement Reinstalling the Power Supply Figure 2-20 Location of Power Cables 3. Lift the handle edge of the power supply enough to allow the bail lock to be disengaged from the bail, fold the bail lock down, and the lower the power supply back into place.
  • Page 41 Figure 2-21 Power Supply Screws and Handles T15 Torx Thumbscrew 5. Carefully tip the workstation back to the upright position. Chapter 2 System Board Removal/Replacement Reinstalling the Power Supply Power Supply Handle T15 Torx Thumbscrew...
  • Page 42: Replacing The Left Side Panel

    System Board Removal/Replacement Replacing the Left Side Panel Replacing the Left Side Panel 1. Replace the left side panel by holding it an angle and inserting its top and bottom hinge hooks with their respective slots in the chassis. Swing the back edge of the panel toward the back of the workstation and press the panel firmly into place.
  • Page 43 Wrapping Up This section contains information to help you confirm that your removal and replacement procedure was successful. In some cases you will need to use specific HP-UX commands and utilities to reconfigure the workstation to recognize the replacement part(s).
  • Page 44: Verifying System Operations

    Wrapping Up Verifying System Operations Verifying System Operations To verify the system operation, follow these steps: 1. Reconnect the power cables and any other cables that were disconnected when opening the workstation. 2. Reconnect all peripheral devices and their associated power cables. 3.
