Removing the Air Divider
1. Remove the PCI retainer clip by pulling evenly in the direction of the
Figure 2-8
Removing the Air Divider
2. Remove the two T-15 Torx screws that secure the air divider to the
3. Note the placement of the air divider for later reference.
4. Grasp the air divider and pull it straight up and out toward you. Set
Chapter 2
"Pull" tabs on the clip and lifting it out of the workstation.
chassis.
it aside with its screws.
System Board Removal/Replacement
Removing the Air Divider
PCI Retainer Clip
Air Divider
25
