HP Visualize c3600 Upgrade Instructions page 37

Reinserting the Memory Cards (DIMMs)
1. Make sure the ejector tabs are angled outward. Next, align the
Figure 2-17 Reinstalling a DIMM
2. Visually inspect and confirm the connection between the memory
3. Repeat steps 1 and 2 for all memory cards.
Chapter 2
notched edge of the memory card with its slot. Insert the memory
card and firmly and evenly push down on each side to lock it into
place. the ejector tabs will angle upward as the memory card is
inserted. Refer to the memory installation label inside the system for
replacing the DIMMs in the correct slots.
card and the system board.
System Board Removal/Replacement
Reinserting the Memory Cards (DIMMs)
37
