HP Visualize c3600 Upgrade Instructions page 33

Figure 2-13
Drive
ta Connector
p Sys. Board Fan
wer Connector
ppy Drive
ta Connector
ttom Sys. Board Fan
wer Connector
ra 2 Wide LVD
SI Connector
Connecting the Cables
2. Inspect the system board to ensure that all cables are connected (all
cables, except the fan cables, are unique and fit only one connector)
and securely seated—loose connections may result in poor system
performance.
Chapter 2
System Board Removal/Replacement
Reconnecting Cables
I/O Fan
Power Connec
Speaker Connec
Front-Panel Disp
Connector
CD Drive Powe
Cable Connec
33
