Controls, LEDs, and Connectors
3.8

Switches

Mechanical switches are provided for debug configuration options. All switch settings are
OFF by default. Setting any switches to the ON state may conflict with normal operating
modes.

Table 3-23 Switch Settings

Switch
SW1.1
SW1.2
SW1.3
SW1.4
68
Options
Manual power enable of 12V
OFF: 12V power is controlled by IPMI
ON: Enable 12V
Manual power enable of POL
OFF: POL power is controlled by IPMI
ON: Enable POL supplies by initiating power up sequence
Manual power enable of AMC and RTM
OFF: AMC and RTM power is controlled by IPMI
ON: Enable AMC and RTM power
Disable IPMC Watchdog Timer
OFF: Watchdog timer is enabled
ON: Disable IPMC Watchdog Timer
ATCA-F125 (6873M Artwork) Installation and Use (6806800J94P)
Controls, LEDs, and Connectors
Default
OFF
OFF
OFF
OFF
