Table 3-18 J8 AMC Bay Connector Pin Assignment (continued)
AMC Bay
Pin Signal
18 +12V
19 GND
20 FIX_GE0_AMCP1_RX+ 54
21 FIX_GE0_AMCP1_RX-
22 GND
23 FIX_GE0_AMCP1_TX+ 57
24 FIX_GE0_AMCP1_TX-
25 GND
26 GA2
27 +12V
28 GND
29 SATA_AMC_RX+
30 SATA_AMC_RX-
31 GND
32 SATA_AMC_TX+
33 SATA_AMC_TX-
34 GND
ATCA-F125 (6873M Artwork) Installation and Use (6806800J94P)
Pin Signal Pin Signal
52 GND 86 GND
53 AMC_RX5+ 87 AMC_ P8_MUX_TX-
AMC_RX5- 88 AMC_ AMC_P8_TX+
55 GND 89 GND
56 IPMBL_SCL 90 AMC_ P8_MUX_RX-
+12V 91 AMC_ P8_MUX_RX+
58 GND 92 GND
59 AMC_TX6+ 93 AMC_ P9_MUX_TX-
60 AMC_TX6- 94 AMC_ P9_MUX_TX+
61 GND 95 GND
62 AMC_RX6+ 96 AMC_ P9_MUX_RX-
63 AMC_RX6- 97 AMC_ P9_MUX_RX+
64 GND 98 GND
65 AMC_TX7+ 99 AMC_ P10_MUX_TX- 133 Unused
66 AMC_TX7- 100 AMC_ P10_MUX_TX+ 134 GND
67 GND 101 GND
68 AMC_RX7+ 102 AMC_ P10_MUX_RX- 136 TCLKC+
Controls, LEDs, and Connectors
Pin Signal
120 Unused
121 Unused
122 GND
123 Unused
124 Unused
125 GND
126 Unused
127 Unused
128 GND
129 Unused
130 Unused
131 GND
132 Unused
135 TCLKC-
Pin Signal
154 Unused
155 GND
156 Unused
157 Unused
158 GND
159 Unused
160 Unused
161 GND
162 Unused
163 Unused
164 GND
165 TCK
166 TMS
167 TRST#
168 TDO
169 TDI
170 GND
