Controls, LEDs, and Connectors
3.6

Backplane Connectors

3.6.1

Zone 1

The following table shows the pinout assignment for the Zone 1 ATCA power connector.
Table 3-9
Contact Number
1 - 4
5
6
7
8
9
10
11
12
13
14
15
16
17 - 24
25
26
27
28
29
30
31
32
33
34
56
Zone 1 Connector P1 Pin Assignment
Destination
Reserved
IPMC Port 2 bit 0
IPMC Port 2 bit 1
IPMC Port 2 bit 2
IPMC Port 2 bit 3
IPMC Port 2 bit 4
IPMC Port 2 bit 5
IPMC Port 2 bit 6
IPMC Port 2 bit 7
IPMC Port C bit 0
IPMC Port C bit 1
IPMC Port C bit 2
IPMC Port C bit 3
Not used
Shelf Ground
Logic Ground
IPM300 ENABLE B
IPM300 48VRTN_A
IPM300 48VRTN_B
IPM300 -48V_A
IPM300 -48V_A
IPM300 ENABLE A
IPM300 -48V_A
IPM300 -48V_A
ATCA-F125 (6873M Artwork) Installation and Use (6806800J94P)
Controls, LEDs, and Connectors
Description
Reserved
Hardware Address Bit 0
Hardware Address Bit 1
Hardware Address Bit 2
Hardware Address Bit 3
Hardware Address Bit 4
Hardware Address Bit 5
Hardware Address Bit 6
Hardware Address Bit 7
IPMB Clock Port A
IPMB Data Port A
IPMB Clock Port B
IPMB Data Port A
Not used
Shelf Ground
Logic Ground
Enable B
Voltage Return A
Voltage Return B
Early -48V A
Early -48V B
Enable A
-48V A
-48V A
