Table 1-1
Standard
EN55022 Class A (EU)
EN 55024 (EU)
FCC 47 CFR Part 15 Subpart B (US),
Class A
AS/NZS CISPR 22 Class A
(Australia/New Zealand)
VCCI Class A (Japan)
Verizon Document
VZ.NEBS.TE.NPI.2004.015: NEBS
Checklist
Directive (EU) 2015/863 (amending
Annex II to Directive 2011/65/EU)
To fulfill the requirements of Telcordia GR-1089,R4-14, use Shielded Twisted Pair
(STP) cables grounded at both ends to connect to the Ethernet ports.
1.3

Mechanical Data

The following table provides details about the blade's mechanical data, such as dimensions
and weight.
Table 1-2
Data
Dimensions
Weight
1.4

Ordering and Support Information

Refer to the ATCA-F125 data sheet for a complete list of available variants and accessories.
Refer to
Appendix B, Related Documentation
Computing sales representative for the availability of other variants.
For technical assistance, documentation, or to report product damage or shortages,
contact your local SMART Embedded Computing sales representative or visit
https://www.smartembedded.com/ec/support/
ATCA-F125 (6873M Artwork) Installation and Use (6806800J94P)
Standard Compliances (continued)
Mechanical Data
Value
30mm x 351mm x 312mm (8U form factor)
2.3kg
Description
EMC requirements (legal) on system level (predefined
SMART Embedded Computing system)
Telecommunications Carrier Group NEBS Checklist
Directive on the restriction of the use of certain hazardous
substances in electrical and electronic equipment
(RoHS).
or consult your local SMART Embedded
Introduction
