Table 3-4 Service Processor Usb Connector (J10); Table 3-5 Sfp+ Connectors Pin Assignment (J4-J7); Table 3-6 Master/Slave Sync Connector (J12-U1) - SMART Embedded Computing ATCA-F125 Assembly, Installation And Use

Controls, LEDs, and Connectors
Table 3-4
USB Pin
1
2
3
4
Table 3-5
Contact
Number
1
2
3
4
5
6
7
8
9
10
1. Configured with a pull-up to allow high speed connection
Table 3-6
RJ-45 Pin
1
2
3
4
54
Service Processor USB Connector (J10)
Function
+0.5 V
DATA_N
DATA_P
GND
SFP+ Connectors Pin Assignment (J4-J7)
Function
GND
TX_FAULT
TX_DISABLE
I2C_SDA
12C_SCL
MOD_ABS
1
RATE_SEL
LOS
GND
GND
Master/Slave Sync Connector (J12-U1)
Function
Transmit +
Transmit -
Receive +
ATCA-F125 (6873M Artwork) Installation and Use (6806800J94P)
Controls, LEDs, and Connectors
Contact
Function
Number
11 GND
12 RX-
13 RX+
14 GND
15 VCCr (+3.3 V)
16 VCCr (+3.3 V)
17 GND
18 TX+
19 TX-
20 GND
