5.8

Power-On Self Test

When the ATCA-F125 is booted, U-boot executes a series of Power-On Self test (POST)
routines. These routines check the functionality of different controllers and other on-board
resources. The result is stored in memory and has the following format.
Table 5-3
Offset
0x0
0x4
0x8
Information about the POST status can also be obtained by reading the SYS FW
PROGRESS IPMI sensor. Depending on the POST status, the sensor holds the following
values.
Table 5-4
Value
0x01
0x02
0x0b
0x0D
0xfd
0x00
ATCA-F125 (6873M Artwork) Installation and Use (6806800J94P)
POST Result Format
Description
Magic word: 0xAA55FCE0
CRC32 checksum over the POST result string
POST result string. This is a zero-terminated string based on the following XML-like
syntax:[<T=tag>[<E>Error_description</E>]*</T>]*
tag identifies the device that was tested. If no POST error was detected, then the
closing tag </T> follows
immediately after the opening tag.
Error_Description contains an error description of the corresponding
Note that the tags can be nested, if for example several subtests are performed
<T>
in one device. See the following example.
<T=FPGA></T>
<T=DRAM><E>Address line</E></T>
<T=PCI><T=BIX></T><T=FIX2></T><T=FIX1></T></T>
<T=SPI><T=BEXT></T></T>
<T=I2C><T=CTRL1></T><T=CTRL2></T></T>
<T=MDIO><T=PHY0></T><T=PHY1></T><T=PHY2><
/T><T=PHY3></T></T>
Post Results in SYS FW PROGRESS IPMI Sensor Reading Data
Description
No memory detected
Memory error. The address and data line test failed.
U-boot image CRC mismatch detected
Wrong CPU speed
SMART EC specific POST error code. For more information, see
One of the remaining POST errors was detected.
U-Boot
tag.
<T>
.
Table 5-5
