Hardware Preparation and Installation
2.5

Blade Configuration

There are no configuration switch settings for normal operational mode. Switch changes
are for activating various debug modes. Setting any switched to the ON state may cause
unpredictable operation.
Product Malfunction
Switches marked as "reserved" may carry production-related functions and can
cause the product to malfunction if the setting is changed.
Do not change settings of switches marked as "reserved".
Product Damage
Setting/resetting the switches during operation can cause damage to the product.
Check and change switch settings before installing the product.
Product Damage
Too much force may damage the reset switch.
Use minimal force when pressing the reset switch.
2.5.1

SATA Drive Installation

An optional SATA drive may be installed on the ATCA-F125. An 80GB drive designed for
extreme temperature and vibration environments has been test and approved for use on
the ATCA-F125. Contact your SMART EC sales representative and order the HDD-80G-
SATA kit which includes the hard drive, all the required mounting hardware, and the
installation instructions.
