Type 6 -
with
OEM Remote Start and
Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of each special note referenced in the diagram (
(+)12V: Gray/Red, pin 24
CAN 2 High: Gray, pin 23
CAN 2 Low: Orange, pin 22
CAN 1 High: Blue, pin 20
CAN 1 Low: White, pin 19
(-) Ground:
Black/Violet, pin 14
Gateway Module
(Black connector Gateway Module
on OBDII connector)
BCM
(Blue plug 'E'
at dash fuse box)
40
52
51
27
39
14
26
25
1
13
45
without
T-Harness
HS CAN 2 High: Tan/Black: 5
HS CAN 1 High: Orange/Green: 7
HS CAN 1 Low: Orange/Brown: 8
Hood Pin
Hood Pin
BCM
(black plug 'G'
(+) Siren Output: Brown: 17
at dash fuse box)
Siren
1 2 3 4 5 6
7
8 9 10 11 12
13 14 15 16
18 19
17
(+) 12V: Red, pin 22
22
20 21
(+) Parking Lights (R): White/Orange, pin 51
(+) Parking Lights (L): Violet/Green, pin 25
HS CAN 2 Low: Tan: 4
(-) Hood Input: Gray: 3
Remote Start Safety
Override Switch
The Remote Start
Safety Override
Switch MUST be in
the ON position.
10: Red: (+) 12V Input
9: Black: (-) Ground
4: Yellow/Red:(-) Ground
3: Brown/Red: (-) Parking Light Output
Fuse 15A
86
87
85
87a
30
2 x 3A Diodes
Directed Digital Solutions FORD12
© 2021-02-04 Directed. All rights reserved.
).
