Directechs FORD12 Installation Manual page 12

Vehicle wiring reference chart
This section provides vehicle wiring information to guide you through the various stages of your installation. Refer to
www.directechs.com for additional information.
Wire Information
Function Color
Ford Edge (Key) 2015
Parking Lights Gray
Parking Lights Interrupt Black/Blue
12V Gray/Red
Ground Black/Blue
CAN 3 High
Green/Orange
(w/o OEM Remote Start)
CAN 3 Low
Gray/Blue
(w/o OEM Remote Start)
CAN 1 High White/Blue or Blue
CAN 1 Low White
CAN 2 High Gray/Orange or
(w/ OEM Remote Start) Orange
CAN 2 Low
Violet/Orange or Violet
(w/ OEM Remote Start)
Hood Pin Blue/Orange
Ford Edge (Smart Key) 2015-2020
Parking Lights Gray
Parking Lights Interrupt Black/Blue
12V Gray/Red
Ground Black/Blue
CAN 3 High
Green/Orange
(w/o OEM Remote Start)
CAN 3 Low
Gray/Blue
(w/o OEM Remote Start)
CAN 1 High White/Blue or Blue
CAN 1 Low White
CAN 2 High Gray/Orange or
(w/ OEM Remote Start) Orange
CAN 2 Low
Violet/Orange or Violet
(w/ OEM Remote Start)
Hood Pin Blue/Orange
12
Pin Polarity Location
11 (-) Headlight switch.
4 Cut Headlight switch.
24 (+) Gateway module right of steering column.
14 (-) Gateway module right of steering column.
18 Data Gateway module right of steering column.
17 Data Gateway module right of steering column.
20 Data Gateway module right of steering column.
19 Data Gateway module right of steering column.
23 Data Gateway module right of steering column.
22 Data Gateway module right of steering column.
14 N.C. BCM-Dash Fuse Box, plug (C).
11 (-) Headlight switch.
4 Cut Headlight switch.
24 (+) Gateway module right of steering column.
14 (-) Gateway module right of steering column.
18 Data Gateway module right of steering column.
17 Data Gateway module right of steering column.
20 Data Gateway module right of steering column.
19 Data Gateway module right of steering column.
23 Data Gateway module right of steering column.
22 Data Gateway module right of steering column.
14 N.C. BCM-Dash Fuse Box, plug (C).
Connector Information
Color
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Directed Digital Solutions FORD12
© 2021-02-04 Directed. All rights reserved.
Pins Ref.
16 A
16 A
24 B
24 B
24 B
24 B
24 B
24 B
24 B
24 B
40 C
16 A
16 A
24 B
24 B
24 B
24 B
24 B
24 B
24 B
24 B
40 C
