Wire Information
Function
Color
Ford Explorer (Smart Key) 2016-2019
Parking Lights
Gray
Parking Lights Interrupt
Black/White
12V
Gray/Red
Ground
Black/White
CAN 3 High
Green/Orange
(w/o OEM Remote Start)
CAN 3 Low
Gray/Blue
(w/o OEM Remote Start)
CAN 1 High
White/Blue or Blue
CAN 1 Low
White
CAN 2 High
Gray/Orange
(w/ OEM Remote Start)
CAN 2 Low
Violet/Orange
(w/ OEM Remote Start)
Hood Pin
Blue/Orange
Ford F-150 (Key) 2015-2020
Parking Lights
Gray
Parking Lights Interrupt
Black/Violet
12V
Green/Red
Ground
Black/Violet
CAN 3 High
Green/Orange
(w/o OEM Remote Start)
CAN 3 Low
Gray/Blue
(w/o OEM Remote Start)
CAN 1 High
White/Blue or Blue
CAN 1 Low
White
CAN 2 High
Gray/Orange
(w/ OEM Remote Start)
CAN 2 Low
Violet/Orange
(w/ OEM Remote Start)
Hood Pin
Blue/Orange
Ford F-150 (Smart Key) 2015-2020
Parking Lights
Gray
Parking Lights Interrupt
Black/Violet
12V
White/Red
Ground
Black/Violet
CAN 3 High
Green/Orange
(w/o OEM Remote Start)
CAN 3 Low
Gray/Blue
(w/o OEM Remote Start)
CAN 1 High
White/Blue or Blue
CAN 1 Low
White
CAN 2 High
Gray/Orange
(w/ OEM Remote Start)
CAN 2 Low
Violet/Orange
(w/ OEM Remote Start)
Hood Pin
Blue/Orange
14
Pin
Polarity
Location
11
(-)
Headlight switch.
4
Cut
Headlight switch.
24
(+)
Gateway module on OBDII connector.
14
(-)
Gateway module on OBDII connector.
18
Data
Gateway module on OBDII connector.
17
Data
Gateway module on OBDII connector.
20
Data
Gateway module on OBDII connector.
19
Data
Gateway module on OBDII connector.
23
Data
Gateway module on OBDII connector.
22
Data
Gateway module on OBDII connector.
14
N.C.
BCM-Dash Fuse Box, plug (F).
11
(-)
Headlight switch.
4
Cut
Headlight switch.
24
(+)
Gateway module at OBDII.
14
(-)
Gateway module at OBDII.
18
Data
Gateway module at OBDII.
17
Data
Gateway module at OBDII.
20
Data
Gateway module at OBDII.
19
Data
Gateway module at OBDII.
23
Data
Gateway module at OBDII.
22
Data
Gateway module at OBDII.
14
N.C.
BCM in passenger kick,, plug (F).
11
(-)
Headlight switch.
4
Cut
Headlight switch.
24
(+)
Gateway module at OBDII.
14
(-)
Gateway module at OBDII.
18
Data
Gateway module at OBDII.
17
Data
Gateway module at OBDII.
20
Data
Gateway module at OBDII.
19
Data
Gateway module at OBDII.
23
Data
Gateway module at OBDII.
22
Data
Gateway module at OBDII.
14
N.C.
BCM in passenger kick,, plug (F).
Connector Information
Color
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Directed Digital Solutions FORD12
© 2021-02-04 Directed. All rights reserved.
Pins
Ref.
16
A
16
A
24
B
24
B
24
B
24
B
24
B
24
B
24
B
24
B
40
C
16
A
16
A
24
B
24
B
24
B
24
B
24
B
24
B
24
B
24
B
40
C
16
A
16
A
24
B
24
B
24
B
24
B
24
B
24
B
24
B
24
B
40
C
