Type 2 - With Oem Remote Start And Without T-Harness - Directechs FORD12 Installation Manual

Type 2 - with OEM Remote Start and
Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of each special note referenced in the diagram (
(+)12V: Brown/Red, pin 24
CAN 2 High:
Gray/Orange, pin 23
CAN 2 Low:
Violet/Orange, pin 22
CAN 1 High:
Blue, pin 20
CAN 1 Low: White, pin 19
(-) Ground:
Black/Blue, pin 14
Gateway Module
(Black connector Gateway Module
on OBDII connector)
2
1
11
12
25
24
37
38
50 51 53
63
64
(+) Parking Lights (RL):
BCM
Violet/Green, pin 53
(Gray Plug 'F'
behind glovebox)
23
without T-Harness
HS CAN 2 High: Tan/Black: 5
HS CAN 1 High: Orange/Green: 7
HS CAN 1 Low: Orange/Brown: 8
Hood Pin Hood Pin
(+) Siren Output: Brown: 17
Siren
BCM
10
(Black Plug 'E'
23
behind glovebox)
36
48 49
62
72
(+) Parking Lights (RR):
White/Orange, pin 48
HS CAN 2 Low: Tan: 4
(-) Hood Input: Gray: 3
(+) Parking Lights (FL): Green/Orange, pin 14
(+) Parking Lights (FR): Brown/Yellow pin 28
1 13
14 25
26 28 37
50
38
Remote Start Safety
Override Switch
The Remote Start
Safety Override
Switch MUST be in
the ON position.
10: Red: (+) 12V Input
9: Black: (-) Ground
4: Yellow/Red:(-) Ground
3: Brown/Red: (-) Parking Light Output
BCM
(Plug 'C' behind glovebox)
3
2
(+)12V: Red,pin 1
1
Fuse 15A 86
4 x 1A Diodes
Directed Digital Solutions FORD12
© 2021-02-04 Directed. All rights reserved.
).
87
85
87a
30
