Directechs FORD12 Installation Manual page 31

Vehicle wiring reference chart
This section provides vehicle wiring information to guide you through the various stages of your installation. Refer to
www.directechs.com for additional information.
Wire Information
Function Color
Ford Escape (Key) 2020
12V (for parking light
Red
relay)
12V2 Brown/Red
Ground2 Black/Blue
HS CAN High 3 (w/o
Green/Orange
OEM Remote Start)
HS CAN Low 3 (w/o
Gray/Blue
OEM Remote Start)
HS CAN High 1 White/Blue or Blue
HS CAN Low 1 White
HS CAN High 2 (w/
Gray/Orange
OEM Remote Start)
HS CAN Low 2 (w/
Violet/Orange
OEM Remote Start)
Parking Lights, Front Left
Blue/Gray
& Right
Parking Lights 2, Rear Left Violet/Green
Parking Lights 2, Rear
White/Orange
Right
31
Pin Polarity Location
1 (+) BCM in passenger footwell, plug (B).
24 (+) Gateway module on OBDII connector.
14 (-) Gateway module on OBDII connector.
18 Data Gateway module on OBDII connector.
17 Data Gateway module on OBDII connector.
20 Data Gateway module on OBDII connector.
19 Data Gateway module on OBDII connector.
23 Data Gateway module on OBDII connector.
22 Data Gateway module on OBDII connector.
52 (+) BCM in passenger footwell, plug (F).
53 (+) BCM in passenger footwell, plug (F).
48 (+) BCM in passenger footwell, plug (F).
Connector Information
Color
Black
Black
Black
Black
Black
Black
Black
Black
Black
Gray
Gray
Gray
Directed Digital Solutions FORD12
© 2021-02-04 Directed. All rights reserved.
Pins Ref.
3 A
24 B
24 B
24 B
24 B
24 B
24 B
24 B
24 B
72 C
72 C
72 C
