Type 4 - Without Oem Remote Start And With T-Harness (Thfoc2) - Directechs FORD12 Installation Manual

Type 4 - without OEM Remote Start and
Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of each special note referenced in the diagram (
Gateway Module
(Black connector Gateway Module
on OBDII connector)
(black plug 'G'
BCM
at dash fuse box)
(Black plug 'F'
at dash fuse box)
1
11 21 31
2 12 22 32
3 13 23 33
24 34
4 14
5 15 25 35
6 16 26 36
7 17 27 37
8 18 28 38
9 19 29 39
40
10 20 30
(+) Parking Lights (R): Brown/Yellow, pin 37
(+) Parking Lights (L): Green/Orange, pin 30
35
with T-Harness (THFOC2)
BCM
Hood Pin Hood Pin
(-) Hood Input: Gray: 3
1 2 3 4 5 6
7 8 9 10 11 12
13 14 15 16
Siren
(+) Siren Output: Brown: 17
18 19
17
22
20 21
(+) 12V: Red, pin 22
Type 2
Type 1
4-pin
connectors
NOT USED
(optional T-Harness)
THFOC2
Remote Start Safety
Override Switch
The Remote Start
Safety Override
Switch MUST be in
the ON position.
(-) Parking Lights Output: Brown/Red
Fuse 15A
86 87
87a
2 x 1A Diodes
Directed Digital Solutions FORD12
© 2021-02-04 Directed. All rights reserved.
).
85
30
