Directechs FORD12 Installation Manual page 38

Wire Information
Function Color
Lincoln Aviator (Smart Key) 2020
12V
Red
(for parking light relay)
12V Gray/Red
Ground Black/Violet
CAN 3 High
Green/Orange
(w/o OEM Remote Start)
CAN 3 Low
Gray/Blue or Blue
(w/o OEM Remote Start)
CAN 1 High Blue
CAN 1 Low White
CAN 2 High
Gray
(w/ OEM Remote Start)
CAN 2 Low
Orange
(w/ OEM Remote Start)
Green/Orange (L);
Parking lights
(Front left & right)
Brown/Yellow (R)
38
Pin Polarity Location
22 (+) BCM - Dash Fuse Box, plug (G).
24 (+) Gateway module on OBDII connector.
14 (-) Gateway Module on back of BCM-Dash Fuse Box.
18 Data Gateway module on OBDII connector.
17 Data Gateway module on OBDII connector.
20 Data Gateway module on OBDII connector.
19 Data Gateway module on OBDII connector.
23 Data Gateway module on OBDII connector.
22 Data Gateway module on OBDII connector.
30
(+) BCM - Dash Fuse Box, plug (F).
37
Connector Information
Color
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Directed Digital Solutions FORD12
© 2021-02-04 Directed. All rights reserved.
Pins Ref.
22 A
24 B
24 B
24 B
24 B
24 B
24 B
24 B
24 B
40 C
