Vehicle wiring reference chart
This section provides vehicle wiring information to guide you through the various stages of your installation. Refer to
www.directechs.com for additional information.
Wire Information
Function
Color
Lincoln Corsair (Smart Key) 2020
12V
Red
(for parking light relay)
12V2
Brown/Red
Ground2
Black/Blue
HS CAN High 3 (w/o
Green/Orange
OEM Remote Start)
HS CAN Low 3 (w/o
Gray/Blue
OEM Remote Start)
HS CAN High 1
Blue
HS CAN Low 1
White
HS CAN High 2 (w/
Gray/Orange
OEM Remote Start)
HS CAN Low 2 (w/
Violet/Orange
OEM Remote Start)
Parking Lights (LR)
Violet/Green
Parking Lights (RR)
White/Orange
43
Pin
Polarity
Location
1
(+)
BCM in passenger footwell, plug (B).
24
(+)
Gateway module on OBDII connector.
14
(-)
Gateway module on OBDII connector.
18
Data
Gateway module on OBDII connector.
17
Data
Gateway module on OBDII connector.
20
Data
Gateway module on OBDII connector.
19
Data
Gateway module on OBDII connector.
23
Data
Gateway module on OBDII connector.
22
Data
Gateway module on OBDII connector.
53
(+)
BCM in passenger footwell, plug (F).
48
(+)
BCM in passenger footwell, plug (F).
Connector Information
Color
Black
Black
Black
Black
Black
Black
Black
Black
Black
Gray
Gray
Directed Digital Solutions FORD12
© 2021-02-04 Directed. All rights reserved.
Pins
Ref.
3
A
24
B
24
B
24
B
24
B
24
B
24
B
24
B
24
B
72
C
72
C
