7. Other Functions
[7] Focus Assist
• • Focus Assist function assigns a color to the
pixels in the shape or boundary area of the
image to inform the user to make the best
focus.
- With this function, user can easily diff erenciate
the focused area from out-focused area
especially shooting with shallow depth of fi eld.
- Available types are [Mono] and [Color] types.
* [Mono] : Background image is mono type.
[Color] : Background image is original color type.
<Focus Assist ON>
<Focus Assist ON>
28 Multi Format LCD Monitor
[8] Range Error
• Pixels with Y' or C' levels exceeding the •
designated levels of Y MAX, Y MIN, C MAX
and C MIN shall blink.
- Analyzes the input signal's Luma(Y') and
chroma information(C') and if the input
signal exceeds the designated minimum
value and maximum value, the pixel shall
blink. This function is to help the user to easily
fi nd out any unwanted level of signals and for
better exposure setting.
<Range Error OFF>
<Range Error ON>
