6. Button Functions

[1] Source Button
• • This product is capable of processing all
input signals usable in SOURCE mode.
• • The input settings are as follows:
1. Press the SOURCE button on the front of the
product and activate the menu below :
2. Use [UP]/[DOWN] Knob to select desired
input source, then enter to confi rm.
3. Input signal resolution displays on the
bottom of OSD menu.
4. Press SOURCE button again to remove the
OSD menu from display.
5. Menu will be disappeared when time set is
over from the screen.
[2] Function Key Set Button
• • Used to make a quick setting of the
Function Key.
1. Press the function button(F1~F4) on the front
of the monitor for more than 2 seconds and
activate the OSD menu as follows.
2. Move to desired function and press [ENTER]
button to select.
3. Once the function is set, press the
Function button(F1~F4) to activate
the function.
Multi Format LCD Monitor 21
