• INTEG Register
Bit
7
Name
—
R/W
—
POR
—
Bit 7~4
Unimplemented, read as "0"
Bit 1~0
INTS1~INTS0: Interrupt edge control for INT pin
00: Disable
01: Rising edge
10: Falling edge
11: Rising and falling edges
• INTC0 Register
Bit
7
Name
—
R/W
—
POR
—
Bit 7
Unimplemented, read as "0"
Bit 6
MF1F: Multi-function interrupt 1 request flag
0: No request
1: Interrupt request
Bit 5
MF0F: Multi-function interrupt 0 request flag
0: No request
1: Interrupt request
Bit 4
INTF: INT interrupt request flag
0: No request
1: Interrupt request
Bit 3
MF1E: Multi-function interrupt 1 control
0: Disable
1: Enable
Bit 2
MF0E: Multi-function interrupt 0 control
0: Disable
1: Enable
Bit 1
INTE: INT interrupt control
0: Disable
1: Enable
Bit 0
EMI: Global interrupt control
0: Disable
1: Enable
• INTC1 Register
Bit
7
Name
—
R/W
—
POR
—
Bit 7~6
Unimplemented, read as "0"
Bit 5
TBF: Time Base request flag
0: No request
1: Interrupt request
Rev. 1.00
4-Key Enhanced Touch I/O Flash MCU
6
5
4
—
—
—
—
—
—
—
—
—
6
5
4
MF1F
MF0F
INTF
R/W
R/W
R/W
0
0
0
6
5
4
—
TBF
I2CF
—
R/W
R/W
—
0
0
90
BS83A04C
3
2
1
—
—
INTS1
—
—
R/W
—
—
0
3
2
1
MF1E
MF0E
INTE
R/W
R/W
R/W
0
0
0
3
2
1
—
—
TBE
—
—
R/W
—
—
0
March 24, 2020
0
INTS0
R/W
0
0
EMI
R/W
0
0
I2CE
R/W
0
