• TKM0THS Register
Bit
7
Name M0K4THF M0K3THF M0K2THF M0K1THF M0K4THS M0K3THS M0K2THS M0K1THS
R/W
R/W
POR
0
Bit 7
M0K4THF: Touch key module 0 KEY4 upper/lower threshold comparison flag
0: Not less than lower threshold or not larger than upper threshold
1: Less than lower threshold or larger than upper threshold
Bit 6
M0K3THF: Touch key module 0 KEY3 upper/lower threshold comparison flag
0: Not less than lower threshold or not larger than upper threshold
1: Less than lower threshold or larger than upper threshold
Bit 5
M0K2THF: Touch key module 0 KEY2 upper/lower threshold comparison flag
0: Not less than lower threshold or not larger than upper threshold
1: Less than lower threshold or larger than upper threshold
Bit 4
M0K1THF: Touch key module 0 KEY1 upper/lower threshold comparison flag
0: Not less than lower threshold or not larger than upper threshold
1: Less than lower threshold or larger than upper threshold
Bit 3
M0K4THS: Touch key module 0 KEY4 upper or lower threshold comparison selection
0: Lower threshold comparison
1: Upper threshold comparison
Bit 2
M0K3THS: Touch key module 0 KEY3 upper or lower threshold comparison selection
0: Lower threshold comparison
1: Upper threshold comparison
Bit 1
M0K2THS: Touch key module 0 KEY2 upper or lower threshold comparison selection
0: Lower threshold comparison
1: Upper threshold comparison
Bit 0
M0K1THS: Touch key module 0 KEY1 upper or lower threshold comparison selection
0: Lower threshold comparison
1: Upper threshold comparison
Rev. 1.00
4-Key Enhanced Touch I/O Flash MCU
6
5
4
R/W
R/W
R/W
0
0
0
72
BS83A04C
3
2
1
R/W
R/W
R/W
0
0
0
March 24, 2020
0
R/W
0
