BS83A04C
4-Key Enhanced Touch I/O Flash MCU
• ED1H Register
Bit 7
Name D15
R/W R/W
POR 0
Bit 7~0 D15~D8: The second Emulated EEPROM data bit 15 ~ bit 8
• ED2L Register
Bit 7
Name D7
R/W R/W
POR 0
Bit 7~0 D7~D0: The third Emulated EEPROM data bit 7 ~ bit 0
• ED2H Register
Bit 7
Name D15
R/W R/W
POR 0
Bit 7~0 D15~D8: The third Emulated EEPROM data bit 15 ~ bit 8
• ED3L Register
Bit 7
Name D7
R/W R/W
POR 0
Bit 7~0 D7~D0: The fourth Emulated EEPROM data bit 7 ~ bit 0
• ED3H Register
Bit 7
Name D15
R/W R/W
POR 0
D15~D8: The fourth Emulated EEPROM data bit 15 ~ bit 8
Bit 7~0
• ECR Register
Bit 7
Name EWRTS1 EWRTS0
R/W R/W
POR 0
Bit 7~6 EWRTS1~EWRTS0: Emulated EEPROM Erase/Write time selection
00: 2ms
01: 4ms
10: 8ms
11: 16ms
EEREN: Emulated EEPROM Erase enable
Bit 5
0: Disable
1: Enable
