Set The Settings In The App - LELY Calm View Installation & Operator's Manual

14. Tighten the bolt (1) on the side of the bracket to lock the position (see figure 9 on page 6-12).
Figure 9. Position and lock the bracket
KEY: 1. Bolt - 2. Horizontal bar
15. Guide the cables via the horizontal bar to a safe position.
6.4

Set the Settings in the App

1. Measure the height from the camera lens to the Solid (concrete / slatted floor).
2. Launch the technician App.
3. Enter height and determine Region of Interest.
Calves: end of Lely Calm.
•
Heifers:
•
Cosmix: End of Lely cosmix.
•
Free range: x= 1 m (3.2 ft).
•
6-12
in n o vato rs in ag ric u ltu re
Installation
