4

Specifications

4.1 Storage & Operational Environmental Specifications
Parameter /
Description
Ambient temperature
Humidity
Altitude
4.2

Power Specifications

Parameter / Description
Aux power supply
PoE++ (802.3bt type 3)
Source current CAN (Aux Power)
Source current CAN (PoE Power)
Source current (Aux Power)
Source current (PoE Power)
4.3

Camera Specifications

Parameter /
Description
Dimensions (H x L x W)
Weight (kg)
Range
IP Rating
Specifications
Minimum
0˚C / 32˚ F
5%
-
Minimum
0.5m / 1.64ft
Nominal
Value
19.2 - 28.8 VDC (96 Wmax)
42.5 - 57.0 VDC (51 Wmax)
19.2 - 28.8 VDC (28.8 Wmax)
19.2 - 28.8 VDC (14.4 Wmax)
19.2 - 28.8 VDC (16.8 Wmax)
19.2 - 28.8 VDC (12 Wmax)
Nominal
170(6.69) x 270(10.62) x
120(4.72) mm(in)
2.6 kg
IP 65
in n o vato rs in ag ric u ltu re
Maximum
35˚C / 95˚ F
100%
2000 mtr / 1.242 mi
Maximum
4m / 13.1ft
4-1
