9. Connect the cables to the camera with the M12 torque tool.
Ethernet (required) marked as ETH.
•
Power supply marked as PWR.
•
1. Required in case of (and / or).
No use of PoE switch / injector.
•
CAN port in use.
•
DIO as output.
•
CAN port (optional).
•
1. In case of heifer monitoring, a tag reader is required.
GPIO peripherals (optional).
•
10. Check the functionality of the Lely Calm View and peripherals before installation.
11. Unplug the power of the Lely Calm View on the not-device side. When PoE is used unplug the Ethernet
on the not-device side.
12. Align adapter plate in such a way that the Lely Calm View is aligned as described per situation (see
Determine placement of the camera on page 6-3).
13. Slide the bracket with the Lely Calm View over the horizontal bar, up to the required position.
Installation
IP 65 compliance
Los of IP 65 rating/compliance.
Place sealing caps on the connectors which are not in use.
Use a double sided ladder when installing the horizontal bar for heifers.
