ACV60E DIRECT VENT
STYLE
Single-sided
WARNING
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious
injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of
this or any other appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch: do not use any phone in your building.
Leave the building immediately.
• Immediately call your gas supplier from a neighbour's phone. Follow the gas sup-
plier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or
the gas supplier.
Installer: Please complete the details on the back cover and leave this manual with the homeowner.
920-306d
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
City Series ®
MODEL
ACV60ENG / ACV60ELP / ACV60EULPG
Homeowner: Please keep these instructions for future reference.
Owners &
Installation Manual
www.regency-fire.com
LISTING AND CODE APPROVALS
These gas appliances were tested
in accordance with AS/NZS 5263.0
& AS/NZS 5263.1.8 and certified by
IAPMO for installation and opera-
tion as described in these instruc-
tions.
Must be installed as per AS/
NZS5601.
Your unit should be serviced an-
nually by an authorised service
person.
www.regency-fire.com.au
02.28.22
