DIRECT VENT GAS POWER VENT FIREPLACE
STYLE
Three sided
Corner Conversion
WARNING
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious
injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
- WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
• Do not touch any electrical switch: do not use any phone in your building.
Leave the building immediately.
• Immediately call your gas supplier from a neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Tested by:
Certified to/Certifié pour:
920-264a
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
City Series ®
MODEL
CB60EPV-NG / CB60EPV-LP
686-927 / 686-928
CSA 2.17-2017
ANSI Z21.88-2017
CSA 2.33-2017
Installer: Please complete the details on the back cover and leave this
manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
Owners &
Installation Manual
www.regency-fire.com
10.30.20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the City CB60EPV-NG and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Regency Fireplace Products City CB60EPV-NG

Summary of Contents for Regency Fireplace Products City CB60EPV-NG

  • Page 1 City Series ® Owners & DIRECT VENT GAS POWER VENT FIREPLACE Installation Manual www.regency-fire.com STYLE MODEL Three sided CB60EPV-NG / CB60EPV-LP Corner Conversion 686-927 / 686-928 WARNING FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage.
