MODELS: Gi29LU-NG
Warning
Fire or explosion Hazard
failure to follow safety warnings exactly could result in serious
injury, death, or property damage.
- Do not store or use gasoline or other flammable vapours and liquids in the vicinity of this or any
other appliance.
- WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
• Do not touch any electrical switch: do not use any phone in your building.
Leave the building immediately.
• Immediately call your gas supplier from a neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Tested by:
Certified to/Certifié pour : ANSI Z21.88-2019
920-391f
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
Regency ® Gi29LU
Gas Insert
Natural Gas
Gi29LU-LP
Propane
Installer: Please complete the details on the back cover and
leave this manual with the homeowner.
Homeowner: Please keep these instructions for future
reference.
Owners &
Installation Manual
www.regency-fire.com
06.09.23
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Regency Fireplace Products Regency Gi29LU
Summary of Contents for Regency Fireplace Products Regency Gi29LU
- Page 1 Regency ® Gi29LU Owners & Installation Manual Gas Insert www.regency-fire.com MODELS: Gi29LU-NG Natural Gas Gi29LU-LP Propane Warning Fire or explosion Hazard failure to follow safety warnings exactly could result in serious injury, death, or property damage. - Do not store or use gasoline or other flammable vapours and liquids in the vicinity of this or any other appliance.
- Page 2 TO THE NEW OWNER Congratulations! You are the owner of a state-of-the-art gas insert by Regency. The Regency gas insert series of handcrafted appliances is designed to provide you with all the warmth and charm of a fireplace at the flick of a switch. The Gi29LU is approved by Intertek for safety and efficiency. As it also bears Regency’s mark, it promises economy, comfort, and security for many trouble-free years to come.
-
Page 3: Table Of Contents
table of contents Dimensions Final Check ................. 59 Wiring Diagram ................60 Operation Unit Dimensions ................4 Faceplate Dimensions ..............5 Owner’s Information Operating Instructions ..............61 Lighting Procedure ..............61 Shutdown Procedure ..............61 Copy of Safety Label ..............6 First Fire .................. -
Page 4: Unit Dimensions
dimensions Unit Dimensions Letter Description Dimensions Dimensions Letter Description Dimensions Dimensions (inches) (mm) (inches) (mm) Width 29-3/4" 756 mm Gas Inlet Front Depth 12-7/16" 316 mm Outerbox Width 28-5/16" 719 mm Electrical Access Height 1-1/8" 29 mm Outerbox Height 20-1/4" 514 mm Electrical Access Rear Depth 7-1/2"... -
Page 5: Faceplate Dimensions
dimensions Faceplate Dimensions Three-Sided Faceplate Four-Sided Faceplate Dimensions Faceplate Width Height Depth Bottom Height Regular Faceplate 40-3/16" (1021 mm) 26" (660 mm) 1-1/4" (32 mm) Regular Faceplate w/ Pre- 40-13/16" (1021 mm) 26-3/8" (670 mm) 1-11/16" (43 mium Surround Flush Faceplate 40-3/16"... -
Page 6: Owner's Information
owner's information Copy of Safety Label A copy of the label that accompanies each Gi29LU gas insert is below. Regency units are constantly improving. Check the safety Duplicate Serial Number Gi29LU Serial Label label on the unit and if it is different from the copy provided DO NOT REMOVE THIS LABEL here, the label on the unit is correct. -
Page 7: Gas Installation Checklist
dimensions Gas Installation Checklist REGENCY GAS INSTALLATION CHECKLIST This general checklist does not contain all pertinent installation details or specifics and does not supersede the guidelines in this manual. Your Regency dealer/installer should use it in conjunction with manual instructions. Please follow all local codes and jurisdictions in authority. Customer: Date Installed: Install Address:... - Page 8 installation REGENCY GAS INSTALLATION CHECKLIST Finishing If applicable, is only noncombustible material installed in the noncombustible areas? Do clearances meet installation and manual requirements? Do the mantels and/or projections comply with the installation manual? If applicable, was the solid fuel fireplace warning plate installed? Appliance Media Setup Do commands from the remote or wall switch light the pilot and main burner? Are the burner media/log set, glass door, and screen installed per instructions in the manual?
-
Page 9: Know Your Appliance
owner's information Know Your Appliance LETTER DESCRIPTION MORE INFO ON PAGE SCREEN ON/OFF SWITCH GLASS DOOR SPARKER BATTERY LOCATION GAS SHUT-OFF VALVE PILOT/ON/OFF CONTROL KNOB FLAME ADJUSTMENT KNOB FAN ADJUSTMENT KNOB AIR SHUTTER ADJUSTMENT ARM REMOTE BATTERY LOCATION Gi29 Direct Vent Gas Insert |... -
Page 10: Important Message
owner's information Important Message Specifications WARNING: FAILURE TO INSTALL THIS SAVE THESE INSTRUCTIONS APPLIANCE CORRECTLY WILL VOID At pressures over 1/2 psig, the pipe to the unit YOUR WARRANTY AND MAY CAUSE must be disconnected. The Gi29LU gas insert must be installed in A SERIOUS HOUSE FIRE. -
Page 11: Copy Of Lighting Plate Instructions
owner's information Copy of Lighting Plate Instructions FOR YOUR SAFETY READ BEFORE LIGHTING POUR VOTRE SÉCURITÉ – À LIRE AVANT LA MISE EN MARCHE WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. -
Page 12: Installer's Information
installer's information Gas Pressure Testing Factory-Built (Metal) General Safety Information Wood-Burning Fireplace 1. The appliance installation must conform with During gas testing at pressures equal-to-or-less- Requirements local codes, or in the absence of local codes, than 1/2 psig. (3.45 kPa), the appliance’s manual with CSA B149.1 (in Canada) or the National shut off valve must be closed to isolate it from the •... -
Page 13: Installation Checklist
installer's information Installation Checklist Minimum Fireplace Dimensions Before installing the vent system, ensure that the The minimum fireplace clearances & dimensions for the Regency gas insert are shown in the following damper plate is open and secure to prevent it from diagram: falling and crushing the liner. -
Page 14: Minimum Fireplace Opening Sizes With Varying Faceplate/Backing Plate Options
installation Minimum Fireplace Opening Sizes with Varying Faceplate/Backing Plate Options Dimensions Minimum Install Minimum Install Minimum Install Minimum Rear Taper Depth Faceplate Width Height Depth Width Regular Faceplate 28-7/16" (722 mm) 20-1/4" (514 mm) 16-11/16" (424 mm) 20" (508 mm) 2-13-16"... -
Page 15: Minimum Clearances To Combustibles
installation Minimum Clearances to Combustibles The clearances listed below are minimum distances unless otherwise stated. A major cause of fires is failure to maintain required clearances (airspace) to combustible materials. It is of the greatest importance that this decorative gas appliance is installed only in accordance with these instructions. -
Page 16: 2-1/2" Mantel Deflector
installation Mantel Clearances Without Mantel Deflector Mantel Clearances with 2-1/2" Mantel Deflector 30" 30" 28" 28" 26" 26" 24" 24" 22" 22" 20" 20" 18" 18" 16" 16" 14" 14" 12" 12" 10" 10" 8" 8" 6" Deflector 6" 4" 4"... -
Page 17: Using Steel Studs & Concrete Board Over Masonry Brick Fireplace
installation Using Steel Studs and Concrete Board Over Masonry Brick Fireplace The masonry front brick facing can be removed and replaced with non-combustible materials such as steel studs and concrete board/dura rock/micor board as per diagram 1, only if safe to do so. Steel stud may also be placed in front of the masonry brick if left in place. This is the preferred method depending on the condition of the masonry brick fireplace. -
Page 18: Leveling Legs Adjustment
installation Leveling Legs Adjustment • The leveling of the appliance must be done prior to hooking up gas line and vent system. 1. The leveling bolts can be installed with bolts from above or below 4. The front leveling bolts can be accessed from the front of the insert, on (preferred method) to level the appliance. -
Page 19: Gas Connection
installation Gas Connection Only people licensed to work with gas piping may make the gas connections to this appliance. 1. If the appliance is installed into an existing chimney system, thoroughly clean the masonry or factory-built fireplace. 2. The appliance has an opening on the left side of the control compartment. A 3/8”... -
Page 20: Alternate Approved Vertical Termination Caps/Adaptor
installation Alternate Approved Vertical Termination Caps/Adaptor Alternate Approved Caps 46DVA-VC Vertical Termination Cap 46DVA-VCH High Wind Cap 46DVA-GK 3" Co-linear Adaptor with flashing In areas with consistently high winds, we recommend using the Simpson Dura-Vent System (46DVA-GK adaptor and 46DVA-VCH high-wind cap). The air intake pipe must be attached to the inlet air collar of the termination cap. -
Page 21: Restrictor Adjustment
installation Restrictor Adjustment Tools needed • Phillips screwdriver Gently lift the screen assembly up and out. Refer to the Screen Removal section. Remove the glass door. Refer to the Glass Door Removal section. Refer to the vent chart to determine the restrictor setting. Locate the restrictor plates and screws. -
Page 22: Vertical Venting/Restrictor Settings For Ng And Lp
installation Vertical Venting/Restrictor Settings for NG and LP Setting #3 Setting #4 4-1/2" open 2" open Setting #2 2-1/2" open Setting #1 Setting #2 1" open 2-1/2" open | Gi29 Direct Vent Gas Insert... -
Page 23: Horizontal Co-Linear Vent Kit (Masonry Fireplaces Only)
installation Horizontal Co-Linear Vent Kit (Masonry Fireplaces Only) APPLICATION This instruction applies to the DuraVent Direct Vent Pro termination system and is intended as a supplement to the applicable Direct Vent Pro instructions. This termination and venting system and the gas appliance were tested and listed by an accredited test agency. Kit # 46DVA-HCL33 includes: 1 Horizontal Termination Cap Two 10' (3 m) long x 3"... -
Page 24: Flue Collar Installation/Removal
installation Flue Collar Installation/Removal 1. Detach the flue collar from the unit by removing the screws and sliding 4. The tabs on the insert will seal the flue collar against the intake inlet the plate backward. and exhaust outlet. Secure with the two screws removed in step 1. Connector plate screws 2. -
Page 25: Air Shutter Adjustment
installation Air Shutter Adjustment The burner aeration is factory set, but may need adjustment due to altitude or the local gas supply. Air shutters increase or decrease the amount of air mixed with fuel, af- fecting combustion and how the flame looks. Low primary air will create a taller, yellower flame, and higher primary air a lower, bluer flame. -
Page 26: Ng System Data
installation Pilot Adjustment 6. When finished reading the manometer, turn off NG System Data the unit, disconnect the hose, and tighten the screw clockwise with a 1/8” flat screwdriver. Min. Supply Pressure 5" WC (1.25kPa) Periodically check the pilot flames. A correct flame pattern has two strong blue flames: one flowing The screw should be snug, but do not Low Setting Man. -
Page 27: Gas Shut Off Procedure
installation Gas Shut Off Procedure Slide the shut-off arm out. Slide shut-off arm back in. Turn gas valve to desired position. If needed, use a flathead screw- driver to turn valve. CLOSED OPEN Alternatively, rotate the knob to turn it into a handle for more leverage. -
Page 28: Conversion From Natural Gas To Propane
Gi29 LP Conversion installation Conversion Kit # 311-977 from NG to LPG Conversion from Natural Gas to Propane for Gi29L using SIT 820 NOVA Gas Valve THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION !! 11. Turn the control knob to the “OFF” posi- Slide the burner tray to the left and out. - Page 29 installation Gi29 LP Conversion • Do not over tighten the screw. Recommended to grip the wrench by the short side. 17. Verify that if the conversion is from NG to LP. The screw must be reassembled with the red o-ring visible (Fig. 5). LPG Configuration Red o-ring visible Fig.5 18. Reassemble the black protection cap (Fig. 6). Fig. 6 • Also check that the pilot and main burner injectors are appropriate for the gas type.
-
Page 30: Derating Kit
Gi29L installation Derate Kit # 311-980 for NG Only Derating Kit for Gi29L using SIT 820 NOVA Gas Valve THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION !! 6. Remove the burner tray (2 screws). Reverse steps 7 to 2. -
Page 31: Panel Installation
installation Gi29 Panel Installation (Part # 311-901, 311-903, 311-904, 311-905, 311-906, 311-907) Panel Installation • Brick/steel/glass panels may discolor a little during operation. This is normal and should not be considered a defect. • Black glass panels: All hand and fingerprints MUST be cleaned off with a soft cloth. Use an ammonia-based cleaner (i.e. glass cleaner) to remove prints before applying heat to the unit. - Page 32 Gi29 Panel Installation installation (Part # 311-901, 311-903, 311-904, 311-905, 311-906, 311-907) For brick/steel panels: 4. Insert the left panel and push until it touches the rear panel. 5. Insert the right panel and push until it touches the rear panel. For glass panels: 6.
- Page 33 Gi29 Panel Installation installation (Part # 311-901, 311-903, 311-904, 311-905, 311-906, 311-907) 9. Install the front panel(s)* by placing between the front of the firebox and the media tray. If the front panel is too tight, there are adjustment slots on the media tray to allow for looser fitting. Loosen the two screws on the media tray and slide it backward or forward as needed. Tighten the screws once the media tray is in the desired location.
-
Page 34: Birch & Oak Log Set Installation (Part #311-931 & 311-934)
installation Gi29 Birch & Oak Log Set Installation (Part # 311-931 & 311-934) Birch & Oak Log Set Installation (Part #311-931 & 311-934) Read the instructions below carefully and refer to the images. If the logs are broken, do not use the unit until they are replaced. - Page 35 Gi29 Birch & Oak Log Set Installation installation (Part # 311-931 & 311-934) 2. Install the log grate with the two screws provided. 4. Fill the media tray with approximately 2lbs of the 3/4” glass, then scatter the black sea vermiculite on top. The glass can cover parts of the front brick panel.
- Page 36 Gi29 Birch & Oak Log Set Installation installation (Part # 311-931 & 311-934) 6. Carefully lay Log 1 on the two pins behind the burner. Make sure the left part of the log does not hit the left portion of the burner. Log 1 The Birch log set (311-931) will look slightly different than shown in the pictures, but the numbering is the...
- Page 37 Gi29 Birch & Oak Log Set Installation installation (Part # 311-931 & 311-934) 8. Place Log 3 on the pin and rotate it until it touches the tab shown below. Ensure that Log 3 is resting directly on the tray with no embers underneath. Log 3 9.
- Page 38 Gi29 Birch & Oak Log Set Installation installation (Part # 311-931 & 311-934) 10. Place Log 5 on the pin under the right burner. Log 5 11. Place Log 6 on the grate with the notch on the middle of the log sitting on the first grate bar and the flat section pointing up. Log 6 does not sit on the front panel - it rests on the tab next to the second grate bar.
- Page 39 Gi29 Birch & Oak Log Set Installation installation (Part # 311-931 & 311-934) 12. Place Log 7 with the notch (shown below) resting on the upper right corner of the second grate bar. Rest the bottom right end of the log on the front panel, ensuring it does not protrude over the bottom edge of the firebox and that there are no embers underneath.
- Page 40 Gi29 Birch & Oak Log Set Installation installation (Part # 311-931 & 311-934) 14. Place Log 9 on the right end of the burner. The log rests on the burner, not on the fifth grate bar. Log 9 15. Place Log 10 on the left side of the burner. Log 10 should not touch Log 6. Readjust the positioning of Log 6 if necessary, enuring it is resting on the tab beside the second grate bar.
- Page 41 Gi29 Birch & Oak Log Set Installation installation (Part # 311-931 & 311-934) Log 1 Log 2 Log 3 Log 10 Log 9 Log 4 Log 5 Log 8 Log 6 Log 7 Final Placement Gi29 Direct Vent Gas Insert |...
-
Page 42: Driftwood Log Set Installation (Part #311-930/P)
installation Gi29 Driftwood Log Set Installation (Part # 311-930/P) Driftwood Log Set Installation (Part #311-930/P) Read the instructions below carefully and refer to the images. If the logs are broken, do not use the unit until they are replaced. Improper positioning of the logs and may create carbon build-up and can alter the unit's performance. - Page 43 installation Gi29 Driftwood Log Set Installation (Part # 311-930/P) 2. Remove pilot shield. 6. Remove the burner by sliding left and up out of the burner tray. 7. Install the Front Log Mount with one screw as shown. 3. Remove 3 screws attaching the pilot shield to the burner tray. 4.
- Page 44 installation Gi29 Driftwood Log Set Installation (Part # 311-930/P) 9. Fill the glass tray with 3/4" glass until it is full. 10. Fill the outside of the Burner Tray and around the Glass Tray with Black Embers as shown. Do not fill the sides of the firebox past the Burner Tray.
- Page 45 installation Gi29 Driftwood Log Set Installation (Part # 311-930/P) 12. Carefully lay Log 1 on the two pins behind the burner. Make sure the left part of the log does not hit the left portion of the burner. Log 1 13.
- Page 46 installation Gi29 Driftwood Log Set Installation (Part # 311-930/P) 15. Place Log 4 on the two pins under the left burner. Log 4 16. Place Log 5 on the pin under the right burner. Log 5 17. Place Log 6 on the right end of the burner. The log rests on the burner. Log 6 | Gi29 Direct Vent Gas Insert 12.21.22...
- Page 47 installation Gi29 Driftwood Log Set Installation (Part # 311-930/P) 18. Place Log 7 on the left of the burner. The log rests on the burner. Log 7 19. Place Log 8 on the pin on the front log mount. The other end will rest on the ember media. Log 8 NOTE: IGNORE TAB UNDER BURNER TRAY, THIS IS...
- Page 48 installation Gi29 Driftwood Log Set Installation (Part # 311-930/P) LOG #1 LOG #7 LOG #2 LOG #6 LOG #3 LOG #4 LOG #5 LOG #8 Final Placement | Gi29 Direct Vent Gas Insert 12.21.22 920-621...
-
Page 49: Screen Removal
installation Screen Removal 1. Gently lift screen assembly out. 2. Place screen assembly where it will not be scratched or broken. Gi29 Direct Vent Gas Insert |... -
Page 50: Glass Door Removal
installation Glass Door Removal 1. Locate and remove the four forward-facing Phillips head screws in the locations shown. 2. Lift glass door up and out. 3. Place glass door in a safe place where it will not be scratched or broken. | Gi29 Direct Vent Gas Insert... -
Page 51: Faceplate/Finishing Trim Installation
installation Gi29 Faceplate/Finishing Trim Installation Faceplate/Finishing Trim Installation (Part # 311-910, 311-912, 311-913, 311-914, 311-915) 3. Fasten the four screws on both sides to attach the faceplate/finish- These instructions are for use with the following products: ing trim. Part # Description 311-910 Faceplate Regular 3-Sided Black... -
Page 52: Backing Plate Installation
installation Gi29 Backing Plate Installation (Part # 311-936, 311-937, 311-938) Backing Plate Installation ?. Remove the four screws located at the front of the unit. These instructions are for use with the following products: 4. Remove the four screws at the front of the unit. Part # Description 311-936... - Page 53 Gi29 Backing Plate Installation installation (Part # 311-936, 311-937, 311-938) 8. Pull the backing plate as far forward as possible against the face- plate, then retighten the screws on both sides. 9. Install the compact screen. Gi29 Direct Vent Gas Insert |...
-
Page 54: Mantel Deflector Installation
installation Gi29 Mantel Deflector Installation (Part #311-940) Mantel Deflector Installation 1. Fasten the two screws provided from the back to attach the mantel 3. Install the compact screen. deflector. 2. Mantel deflector installed. | Gi29 Direct Vent Gas Insert... -
Page 55: Premium Faceplate Surround Installation
installation Gi29 Faceplate Surround Installation (Part # 311-920, 311-921, 311-922, 311-923, 311-924) Premium Faceplate Surround Installation 3. Lift the faceplate and faceplate surround up from the top edge and These instructions are for use with the following products: refer to "Faceplate / Finishing Trim Installation". PART # Description 311-920... -
Page 56: Traditional Faceplate Surround Install (Part #311-927, 311-928)
installation Gi29 Faceplate Surround Installation (Part # 311-927, 311-928) Traditional Faceplate Surround Installation (Part #311-927, 311-928) These instructions are for use with the following products: 4. Tighten the bottom screws (x4). PART # Description 311-927 Gi29 Traditional Surround Black 311-928 Gi29 Traditional Surround Brushed Antique Copper 1. -
Page 57: Hearth Trim Installation - Trimming To Height
installation Gi29 Hearth Trim Installation (Part # 311-941 ) TRIMMING TO HEIGHT Hearth Trim Installation - Trimming to Height 1. Remove the lower section of hearth trim by pulling evenly from both 3. Slide the lower section back into the clips on the rear of the upper sides. section. 2. If using a grinder (recommended): trim the lower section to height referring to the installation table for the amount to remove. Installation Table Required install height Height to cut off lower section 6” (Max) None 5 1/2” 1/2” 5” 1”... -
Page 58: Hearth Trim Installation - Mounting Hearth Trim
installation Gi29 Hearth Trim Installation (Part # 311-941 ) MOUNTING HEARTH TRIM Hearth Trim Installation - Mounting Hearth Trim 1. Loosely attach the hearth trim using the slots in the unit's base and 2b. With premium surround: slide the hearth trim as far back as pos- the included screw. sible (careful not to scratch it) and tighten the screws. 2a. Without premium surround: slide the hearth trim as far forward as possible (careful not to scratch it) and tighten the screws. 920-483 12.17.21 | Gi29 Direct Vent Gas Insert... -
Page 59: Optional Wall Thermostat
installation Optional Wall Thermostat Final Check A wall thermostat may be installed if desired; follow Before leaving this unit with the customer, the the wiring diagram below. FPI offers an optional installer must ensure that the appliance is firing programmable thermostat, but any 250-750 millivolt correctly. -
Page 60: Wiring Diagram
installation Wiring Diagram This heater does not require a 120 V A.C. supply for operation. In case of a power failure, the burner switch and the remote control/thermostat will continue to operate. However, a 120 V A.C. power supply is needed for the fan/blower operation. S.I.T. -
Page 61: Operation
operating instructions Operating Instructions Shutdown Procedure On/Off Switch 1. Switch On/Off lever to the OFF position. Before operating this appliance, proceed through the following checklist. 2. Allow the unit to cool then remove the glass barrier. 1. Read and understand these instructions before 3. -
Page 62: Proflame I Remote Control Operating Instructions
owner's information Proflame I Remote Control Operating Instructions PROFLAME I REMOTE CONTROL OPERATING INSTRUCTIONS IMPORTANT:The Proflame Transmitter 1 is an integrated part of the TECHNICAL DATA Proflame 1 System, which consists of these elements: • Proflame 1 Transmitter, to be used in conjunction with: REMOTE CONTROL •... - Page 63 Turn on the Appliance With the system OFF, press the ON/ OFF Key on the Transmitter. The Transmitter display will show some Fig. 8 owner's information other active Icons on the screen. At the same time the Receiver will ac- tivate the appliance.
- Page 64 owner's information LOW BATTERY POWER DETECTION Transmitter The life span of the remote control batteries depends on various factors: quality of the batteries used, the number of ignitions of the appliance, the number of changes to the room thermostat set point, etc. When the Transmitter batteries are low, a Battery Icon will appear on the LCD display of the Transmitter (Fig.
-
Page 65: Proflame I Remote Receiver Battery Replacement
owner's information Proflame I Remote Receiver Battery Replacement Remote Receiver/Battery Holder Battery Replacement & Battery Back up if 120 volt Remote Receiver Battery Replacement power is lost witihin home How to replace/add the batteries on remote receiver. Note:4 AA batteries are mandatory in the remote receiver to operate appliance when using remote control. The remote receiver will be located on the bottom right hand side of appliance next to the fan speed controller. -
Page 66: Operating Procedure For Remote Control
operating instructions Operating Procedure for Remote Control Functionality of the Receiver Low Battery Detection (Receiver) Warnings and Cautions The receiver is supplied by four AA batteries (see The duration of the remote control batteries depends • Fire hazard. Can cause severe Fig. -
Page 67: Normal Operating Sounds Of Gas Appliances
maintenance Normal Operating Sounds of 4. Check the burner’s position and condition pe- 6. Keep the area near the appliance clear and free riodically, as well as the burner flame, making from combustible materials, gasoline, and other Gas Appliances sure it is steady, not lifting or floating. If there flammable vapours and liquids. -
Page 68: Door Glass
maintenance Door Glass General Vent Maintenance Sparker Battery Change Your Regency insert is supplied with high Conduct an inspection of the venting system 1. Pull the sparker box out to access the battery -temperature Neoceram glass that will withstand semiannually. Areas to inspect are as follows: cover. -
Page 69: Fan Replacement
S.I.T. Valve maintenance Fan Replacement To access the side and rear panels, disconnect the gas and venting (see the venting and flue installation sections in this manual for steps). You cannot access the blower from the front of the appliance. 1. -
Page 70: Valve Replacement
maintenance Valve Replacement Before you begin: • Shut off the gas supply to the unit. • Disconnect all electrical supply to the unit. Always let the appliance cool to room temperature before servicing. • When the glass is cold and the appliance is lit, condensation may fog the glass. Condensation is normal and will disappear in a few minutes as the glass heats up. - Page 71 maintenance 5. Disconnect the spark electrode & remove both extension knobs by pulling 7. Remove the Phillips head screw securing the sparker box switch. these out toward you. PHILLIPS SCREW Extension knobs 6. Remove the 16 screws securing the valve tray. 8.
-
Page 72: Gas Maintenance - Recommended Annual Routine
Gas Maintenance maintenance Gas Maintenance - Recommended Annual Routine Recommended Annual Routine Maintenance for Gas Fireplaces, Stoves and Inserts In order for your Regency appliance to continue to provide comfort to your home periodic maintenance must be performed to ensure it is operating at peak efficiency. The items in the list should be checked by a licensed gas service technician during the annual service check. Your unit may require more frequent maintenance checks if you notice any changes in how it operates. Operational changes to look for can include, but are not limited to, extended start up time, increased fan noise, residue/carbon build up, white build up on the glass/firebox, increased operating noise etc. Should any of these or other conditions arise, discontinue use and schedule a service check with your local licensed gas technician. The list below shows items your licensed service technician will need to check and service at least annually. Clean Inspect Check • Glass • Pilot assembly • Voltage on thermocouple/thermopile (mil- • Interior bricks / panels • Burner livolt models) • Burner ports & burner air shutter •... -
Page 73: Parts - Main Assembly
parts list Parts - Main Assembly Gi29 Direct Vent Gas Insert |... - Page 74 parts list Parts - Main Assembly ITEM PART # DESCRIPTION ITEM PART # DESCRIPTION 311-774/P Valve Assembly - NG 910-386 Quick Dropout Thermocouple 0.290.216 311-776/P Valve Assembly - LP 910-096 Novasit Pilot Hood 3 Way 910-478 Valve NG/LP SIT High/Low 820.844 910-432 Novasit Pilot Tubing With Nuts 910-038/P...
-
Page 75: Faceplates/Accessories
parts list Faceplates/Accessories ITEM PART # DESCRIPTION ITEM PART # DESCRIPTION 312-936 Backing Plate Oversized 311-940 Mantel Deflector 311-937 Backing Plate Custom 3-Sided* 311-941 Adjustable Hearth Trim 311-938 Backing Plate Custom 4-Sided* 311-934 Oak Log Set 312-193 Bracket Backing Plate 311-931 Birch Log Set 311-920... -
Page 76: Warranty
warranty Limited Lifetime Warranty FPI Fireplace Products International Ltd. (for Canadian customers) and Fireplace Products U.S., Inc. (for U.S. customers) (collectively referred to herein as “FPI”) extends this Limited Lifetime Warranty to the original purchaser of this appliance provided the product remains in the original place of installation. The items covered by this limited warranty and the period of such coverage is set forth in the table below. - Page 77 warranty At all times FPI reserves the right to inspect reported complaints on location in the field claimed to be defective prior to processing or authorizing of any claim. Failure to allow this upon request will void the warranty. All warranty claims must be submitted by the dealer servicing the claim, including a copy of the Bill of Sale (proof of purchase by you).
- Page 78 warranty Limitations of Liability: The original purchaser’s exclusive remedy under this warranty, and FPI’s sole obligation under this warranty, express or implied, in contract or in tort, shall be limited to replacement, repair, or refund, as outlined above. IN NO EVENT WILL FPI BE LIABLE UNDER THIS WARRANTY FOR ANY INCIDENTAL OR CONSEQUENTIAL COMMERCIAL DAMAGES OR DAMAGES TO PROPERTY.
- Page 79 warranty Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase.
- Page 80 warranty | Gi29 Direct Vent Gas Insert...
- Page 81 notes Gi29 Direct Vent Gas Insert |...
- Page 82 notes | Gi29 Direct Vent Gas Insert...
- Page 84 Installer: Please complete the following information Dealer Name & Address: __________________________________________________________________ ______________________________________________________________________________________ Installer: ______________________________________________________________________________ Phone #: ______________________________________________________________________________ Date Installed: __________________________________________________________________________ Serial #:_______________________________________________________________________________ Printed in Canada Regency and Regency Horizon are trademarks of FPI Fireplace Products International Ltd. ® © Copyright 2023, FPI Fireplace Products International Ltd. All rights reserved.
