Regency Fireplace Products City Series ACB40ENG Owners & Installation Manual

Zero clearance direct flue gas fireplace
Hide thumbs Also See for City Series ACB40ENG:
Table of Contents

Advertisement

Quick Links

Download this manual
Zero Clearance Direct Flue Gas Fireplace
STYLE
Three sided
Warning
Fire or explosion Hazard
failure to follow safety warnings exactly could result in serious
injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
- WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
• Do not touch any electrical switch: do not use any phone in your building.
Leave the building immediately.
• Immediately call your gas supplier from a neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.
920-121
City Series
MODEL
ACB40ENG / ACB40ELP / ACB40EULPG
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
®
Owners &
Installation Manual
LISTINGS AND CODE APPROVALS
These gas appliances have been
tested in accordance with AS/NZS
5263.0 & AS/NZS 5263.1.8:2016
and have been certified by IAPMO for
installation and operation as described
in these Installation and Operating
Instructions.
Must be installed as per AS/NZS5601.
Your unit should be serviced
annually by an authorised service
person.
www.regency-fire.com.au
PRIMARILY A DECORATIVE AND NOT A
HEATING APPLIANCE.
DO NOT MODIFY THIS APPLIANCE.
03.12.20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the City Series ACB40ENG and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Regency Fireplace Products City Series ACB40ENG

Summary of Contents for Regency Fireplace Products City Series ACB40ENG

  • Page 1 ® City Series Owners & Zero Clearance Direct Flue Gas Fireplace Installation Manual LISTINGS AND CODE APPROVALS These gas appliances have been tested in accordance with AS/NZS 5263.0 & AS/NZS 5263.1.8:2016 and have been certified by IAPMO for installation and operation as described in these Installation and Operating Instructions. Must be installed as per AS/NZS5601. Your unit should be serviced annually by an authorised service person.
  • Page 2 To the New Owner: Congratulations! You are the owner of a state-of-the-art Gas Fireplace by REGENCY . The City Series are hand crafted appliances and have ® been designed to provide you with all the warmth and charm of a wood fireplace at the flick of a switch. The ACB40E City Series has been approved by IAPMO for both safety and efficiency. As it also bears our own mark, it promises to provide you with economy, comfort and security for many trouble free years to follow. Please take a moment now to acquaint yourself with these instructions and the many features of your Regency Fireplace. ® | City Series ACB40E...

  • Page 3: Table Of Contents

    table of contents Vertical Terminations ...........50 Owner's Information Unit Installation with Horizontal Termination ....51 Copy of Data Badge ............4 DuraVent Vertical Termination........53 Dimensions ..............5 Vertical Termination-102 mm x 175 mm Flueing ..54 Important Message ............6 Vertical Flue Extension Kit ...........56 Before You Start .............6 Ceiling Firestop / Firestop Spacer (Part #946-757) ..56 General Safety Information ..........7 System Data ..............57 Lighting Procedure ............8 High Elevation ..............57 Shutdown Procedure .............8 Gas Line Installation ............57 Copy of the Lighting Plate Instructions ......9 Pilot Adjustment ............57 Proflame II Remote Control Operating Instructions ..10 Gas Pipe Pressure Testing ..........57 Outer Safety Glass Panel Installation / Removal ..14 885 S.I.T. Valve Description .........57...

  • Page 4: Copy Of Data Badge

    safety decal This is a copy of the label that accompanies Direct Flue Gas Fireplace. We have printed a copy of the contents here for your review. The safety label is located on the front inside base of the unit, visible when the outer front panel is removed. NOTE: Regency units are constantly being improved. Check ® the label on the unit and if there is a difference, the label on the unit is the correct one. Copy of Data Badge Regency Gas Fireplace Distributed by: Propane ULPG Gas Type Western Australia: Air Group Australia ACV40ENG ACV40ELP ACV40EULPG Model 28 Division St Welshpool, WA 6106 ACB40ENG ACB40ELP ACB40EULPG Eastern Australia...

  • Page 5: Dimensions

    dimensions Dimensions Note: Height Dimension may vary depending on the height of the leveling legs. Note: These units are non-load bearing. City Series ACB40E |...

  • Page 6: Important Message

    owner's information Important Message WE RECOMMEND REMOVING THE CHILDREN AND ADULTS SHOULD BE GLASS WITH THE GLASS VACUUM SAVE THESE INSTRUCTIONS ALERTED TO THE HAZARDS OF HIGH HOLDERS SUPPLIED BY THE MANU- SURFACE TEMPERATURES, ESPE- FACTURER. LOWER THE GLASS TO City Line Direct Flue Fireplaces must be installed CIALLY THE FIREPLACE GLASS, AND in accordance with these instructions. Carefully...

  • Page 7: General Safety Information

    owner's information General Safety Information 1. The appliance installation must conform with local codes or, in the absence of local codes, with the current Installation and Building Codes. 2. The appliance when installed, must be electri- cally grounded in accordance with local codes. 3. See general construction and assembly in- structions. The appliance and flue should be enclosed. 4. This appliance must be connected to the speci- fied flue and termination cap to the outside of the building envelope. Never flue to another room or inside a building. Make sure that the flue is fitted as per Flueing instructions.

  • Page 8: Lighting Procedure

    owner's information Lighting Procedure IMPORTANT: The remote control system supplied with this appliance has Note: The first try for ignition will last approximately 60 seconds. If there is no several options for starting/operating the appliance using the battery holder flame ignition (rectification) the board will stop sparking for approximately and ON/OFF key on the hand held transmitter. 35 seconds. After wait time , the board will start second try for ignition by Prior to operating this appliance, please read the remote control operating sparking for approximately 60 seconds . If there is still no positive ignition instructions (packaged with remote control) to understand how to operate the board will go into lock out. this remote control system. The system will need to be reset as follows: 1. Ensure the battery holder switch is in the Remote position and / or wall mounted battery holder (if equipped) is in the <REMOTE> position. a) Turn the system off by pressing the ON/OFF button on the remote. 2. Press and release the ON/OFF button on the remote handheld transmitter b) Wait 5 minutes then repeat from step 2. (see Diagram 1). An audible beep should be heard from the receiver. If not using the remote, the unit can also be turned on by sliding the battery holder switch to the <ON> position (if equipped). Shutdown Procedure 1. Press the ON/OFF button on the remote 2. If service is to be performed- you must disconnect power and shut off gas to the unit. On/Off Button Diagram 1 Remote shown in Manual Mode on Hi...

  • Page 9: Copy Of The Lighting Plate Instructions

    owner's information Copy of the Lighting Plate Instructions FOR YOUR SAFETY READ BEFORE LIGHTING SUITABLE ONLY FOR INDOOR INSTALLATION This appliance must be installed in accordance with local codes, if any. If none, follow the current AS/INZS 5601. WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life.

  • Page 10: Proflame Ii Remote Control Operating Instructions

    owner's information PROFLAME II REMOTE CONTROL OPERATING INSTRUCTIONS Proflame II Remote Control Operating Instructions IMPORTANT:The Proflame Transmitter 2 is an integrated part of the TECHNICAL DATA Proflame 2 System, which consists of these elements: • Proflame 2 Transmitter, to be used in conjunction with: REMOTE CONTROL •...
  • Page 11 owner's information Temperature indication Display Remote‑Flame Control With the system in the "OFF" position, press the Thermostat Key and The Proflame has six (6) flame levels. With the system on, and the flame the Mode Key at the same time. Look at the LCD screen on the transmit- level at the maximum in the appliance, pressing the Down Arrow Key ter to verify that a C or F is visible to the right of the room temperature once will reduce the flame height by one step until the flame is turned off.
  • Page 12 owner's information Smart Thermostat (Transmitter Operation) Remote dimmer control (Light)** The auxiliary function controls the AUX power outlet by the dimmable The Smart Thermostat function adjusts the flame height in accordance light control. To activate this function use the Mode Key (fig. 1) to index to the difference between the set point temperature and the actual room to the AUX icon (fig.
  • Page 13 owner's information Continuous Pilot/Intermittent Pilot (CPI/IPI) selection 5. "Clr" will remove a mode—use the up or down arrow while holding down ON/OFF and MODE (mode icon will disappear once removed). Note: Power vent models do not have a Continuous 6. Use the "MODE" button to move to the next function. Pilot option.

  • Page 14: Outer Safety Glass Panel Installation / Removal

    owner's information Outer Safety Glass Panel (Barrier Glass) Installation / Removal To watch the safety barrier glass installation video click here. Note: safety glass panels must be installed to operate fireplace 3. T ilt the top of the glass panel inward and lift up and underneath the upper front panel of the outside frame. Hook the glass panel WARNING: GLASS HANDLING onto the pins and also onto the two angle adjustment brackets lo- cated on the frame in two locations as shown in the diagram below.
  • Page 15 owner's information Outer Safety Glass Panel (Barrier Glass) Installation / Removal Note: safety glass panels must be installed to operate fireplace Note: A fter the side panel has been adjusted so it is installed at 90º to the 4. With front panel installed, proceed to install the side panel(s). unit and not flaring in or out, check to ensure there is no gap between I dentify the left and right side panels before installing. Facing the front of the front and side panel. If there is a gap as shown below, slide the side the unit, the right panel will show an arrow pointing to the front of the unit panel to adjust the position and close the gap. as shown in the diagram below. Direction arrow on side panel bracket, should point toward front of unit 5. Lift up the side panel with the supplied glass clamps (see procedure on previous page). Tilt the side of the glass panel inward and lift up and under- neath the upper side panel and hook the 2 outer hooks on to the pins, there 6. Repeat Steps 4 and 5 to install the opposite side panel.

  • Page 16: Inner Glass Panel Installation / Removal

    owner's information Inner Glass Panel (Firebox Glass) Installation / Removal To watch the firebox installation video click here. Note: glass panels must be installed to operate fireplace. Push side glass WARNING: GLASS HANDLING panel firmly to back wall We recommend using the glass vacuum holders supplied by the manufac- until springs are turer. Lower the glass to rest in a safe place, this is to prevent damage to the compressed— glass edges. Extra care must be taken when removing/installing the glass. then close Breakage or damage to the edge of the glass which occurs as a result of clamps. careless handling will not be covered under warranty. • W e recommend handling the glass with supplied vacuum clamps •...
  • Page 17 owner's information 5. E nsure all 7 front clamps are in the open position to allow clearance for Note: Ensure that the front glass is centered and evenly spaced with side glass the glass. (3 sided unit) - open to release glass clamps to remove from surface of glass. Open clamps prior to plac- ing front glass panel Open clamps to release pressure on 6. L ift up the front panel using the supplied vacuum clamps and position into the springs the lower front channel–ensure the front panel is accurately centered—with the front panel in position—secure in place by closing the 3 lower clamps and 4 upper clamps. 7. R eturn to the side panel(s), and release the upper and lower clamps. The springs will release and push the glass side panel forward slightly—this will Press glass vacuum clamps in open position firmly onto surface of glass. Bring create a seal between the front and side panels. When the junction between handles together to close. the front and side glass panels is sealed, close the clamps to secure the side panel(s) in place. 8. T o remove the glass panels—always remove the side panel(s) (for 3 sided units) before removing the front panel.

  • Page 18: Maintenance Instructions

    owner's information 3. Check for evidences of excessive condensation, Maintenance Instructions Glass Replacement such as water droplets forming in the inner liner, and subsequently dripping out the joints, In the flue that you break your glass by impact, 1. Always turn off the gas valve before cleaning. Continuous condensation can cause corrosion purchase your replacement from an authorized For relighting, refer to lighting instructions. Keep of caps, pipe, and fittings. It may be caused Regency dealer only. Replacement glass is shipped the burner and control compartment clean by by having excessive lateral runs, too many already installed into the door frame. Reinstall as per brushing and vacuuming at least once a year.

  • Page 19: Installer's Information

    installer's information This includes: General Safety Information Installation Checklist 1. Clocking the appliance to ensure the correct 1. The appliance installation must conform with 1. Locate appliance. Refer to the following sections: firing rate (rate noted on label 28,500 Btu/h NG/ local codes or, in the absence of local codes, a) Locating Your Fireplace LP) after burning appliance for 15 minutes. with the current Canadian or National Gas b) Clearances Codes, CAN1-B149 or ANSI Z223.1 Installation c) Combustible Mantel Clearances 2. If required, adjusting the primary air to ensure...

  • Page 20: Locating Your Gas Fireplace

    installer's information Locating Your Gas Fireplace Unit Assembly Prior to Installation 1. When selecting a location for your fireplace, Before you start ensure that the clearances are met. tooltip The ACB40E has only 2 standoffs at the back that need assembly before installation. 2. The appliance must be installed on a flat, solid, WARNING! Risk of Fire! Comply with all minimum clearances. continuous surface For example a wood, metal or concrete floor or in a raised (on the wall) ap- Back standoff assembly ACB40E plication. The appliance must be installed on a metal or wood panel extending the full width Take each standoff off the unit by removing one and depth of the appliance.

  • Page 21: Clearances

    installation Clearances Flue Clearances to Combustibles Clearance: 3 sided Dimension Measured From: Horizontal - Top 76mm A: From Floor Min. 0mm Bottom of Fireplace Opening Horizontal - Side 51mm A1 : Mantel Height (min.) Top of Fireplace Opening Horizontal - Bottom 51mm B: Sidewall (on one side) 216mm Side of Fireplace Opening Vertical 51mm C: Enclosure Width (min.) 1230mm Minimum inside dimensions Passing through wall/ floor/ceiling - when 38mm D: Mantel Depth (max.) firestop is used. E: Alcove Width 2134mm Side wall to side wall (min.)
  • Page 22 installation Clearances Floor to ceiling with top opening Low framing with flues in front/sides or top Full framing with low flues in front or sides Full framing with flues in front or sides | City Series ACB40E...

  • Page 23: Mantel Clearances

    installation Mantel Clearances Combustible mantel clearances from top of front facing are shown in the diagram on the right. 13mm Plasterboard, timber, timber panel, etc. 305mm 229mm 130mm Top of Bottomof Fireplace Fireplace Opening Opening 383mm Mantel Leg Clearances Combustible mantel leg clearances as per diagram: MANTEL LEG 216mm City Series ACB40E |...

  • Page 24: Framing Dimensions

    installation Framing Dimensions NOTE: Framing may be constructed of combustible material (ie. 51x102mm) and does not require steel studs. Two (2) optional steel stud kits may also be purchased. These kits may be used in place of the conventional wood framing as shown below. It comes as a compact kit (flush to the appliance on all sides)or an extended kit. The extended kit protrudes beyond each side of the appliance as shown on the front cover of this manual. There is also an optional hearth kit which may be purchased as shown on the front cover of this manual. These kits are highly recommended as it was designed specifically for the product to facilitate ease of installation. See instructions in this manual for details. Framing Description ACB40E Dimensions Framing Height 949mm Framing Width 1232mm Framing Depth 483mm Minimum Height to Combustibles 1600mm Flue Centerline Height 1429mm Gas Connection Opening Height 51mm Gas Connection Height 106mm Gas Connection Inset 330mm Gas Connection Opening Width 89mm Note: A combined minimum of 774 square centimetres of open area is required for the convection air outlet to cool the enclosure. Ensure clearances for Convection Air Outlets are met. See clearances ACB40E (3 sided) in this manual as there are different methods as to how this can be achieved. Note: Only basic framing dimensions are shown. The framing may also extend beyond the appliance on either side and also extend out front if a hearth is desired. See clearance/finishing requirements for details. Note: Unit is not load bearing. All finished materials must be supported by framing. Maximum mate- rial dimensions 51mm x 102mm for Header studs (installed on edge and flat) Note: This appliance must be installed on a solid surface such as a plywood floor...

  • Page 25: Optional Framing Kit Installation

    installation Optional Framing Kit Installation To watch the extended chase framing kit installation video click here: http://bit.ly/2uqaUTz CITY SERIES Optional Extended and Compact Framing Kits Tools/hardware needed are as follows: The following procedure shows the assembly of the extended framing kit—the - Level installation of the compact framing kit is identical except part 656-371 (Step 22) - Stud fi...
  • Page 26 CITY SERIES installation 2. Install Part B1 + B2 to Part A with 2 screws on each side from the front of 4. Slide unit into position. Check to ensure that the unit is level from front to back the unit. and side to side and Parts A + B are square.
  • Page 27 CITY SERIES installation 8. Attach O (x2) and Q (X2) to the top of Part B2 using screws in loca- 10. Attach O (x2) with one screw to B3 and swing Part O in as shown to tions shown below. keep out of the way until further in the installation.
  • Page 28 CITY SERIES installation 14. Secure Part Q to top Part S with 1 screw each. 17. Position Part M (x2) to nest in behind Part I (x2) and secure to Part I with 3 screws each and Part L with 4 screws each. See 2 drawings shown below noting orientation of Part M.
  • Page 29 CITY SERIES installation 21. Attach the opposite corner brace Part P to the RIGHT side and Part 18. Swing Top Part O out from B3. Top Part O H with 4 screws from the top. 19. Secure all Part O with 4 screws each. Attach Part P (Right) to the RIGHT SIDE + H1 22.
  • Page 30 CITY SERIES installation Extended Kit Overall Dimensions: Width: 1537 mm Depth: 475 mm Height: min. 2032 mm max. 3048 mm Compact Kit Overall Dimensions: Width: 1537 mm Depth: 475 mm Height: min. 2032 mm max. 3048 mm Min/Max Height measured from base of appli- ance/ fi...

  • Page 31: Chase Flue Installation

    installation Chase Flue Installation C40 Chase Vent Framing Clearances Framed opening must be between 102mm and 114mm and at least 1073mm wide to accommodate the chase vent. The top chase vent opening must be 76mm or less from the top of the case enclosure. Min.
  • Page 32 installation C40 Chase Vent Finish Detail Finish edges of plasterboard with trim or corner bead. Edge nish must not decrease opening area below 130in (3.25”x40”) 839cm (83mm x 1016mm) | City Series ACB40E...
  • Page 33 installation C40 Chase Vent Installation Example Frame opening for vent Screw Chase vent to Framing Use at least 3 sets of screws (See Vent Framing Clearances Page) to keep the vent at against framing Plasterboard Frame wall with nishing material If necessary, mark where the Cut hole in nishing material chase vent is located before...

  • Page 34: Chase Flueing

    installation Chase Flueing Note: The enclosure opening cannot be any lower than 0-76mm from the top of the enclosure for all installations. Minimum height of enclo- sure from base of appliance is 1600mm. CHASE VENTING A minimum 774cm opening in the enclosure is required to maintain safe operating temperatures. This can be achieved in a number of ways including the examples shown below. Warning: DO NOT cover or place objects in front of the air outlet(s). Regency Chase Vent Dimensions: Custom chase vent (839cm...

  • Page 35: Optional Front Grill Installation

    CITY SERIES installation OPTIONAL FRONT GRILL INSTALLATION Optional Front Grill Installation This optional grill meets the requirement of the 774cm required for the enclosure in all installations and is designed to keep the enclosure cool. To install the front grill - frame an opening of 111mm H x 994mm W. The finished facing material should be attached and be the same size as the framed opening to eliminate gaps.

  • Page 36: Optional Side Grill Installation

    installation CITY SERIES Optional Side Grill Installation OPTIONAL SIDE GRILL INSTALLATION ACB40E WITH WOOD CHASE These optional grills meet the requirement of the 774 square centimetres required for the enclosure in all installations and are designed to keep the enclosure cool. To install the side grills - frame an opening of 211mm H x 211mm W.

  • Page 37: Wall Board/Plasterboard Installation

    installation Wall Board/Plasterboard Installation WARNING! Risk of Fire! Comply with all minimum clearances to combustibles as specified. Finishing Instructions It is important to follow the framing and finishing instructions to ensure proper placement of fireplace into the surrounding framing/finishing materials. Wall board materials 13mm thick are specified in this installation manual to properly align with the optional finishing methods offered with this appliance. The ACB40E may be finished to the appliance opening with 13mm thick plasterboard. • Ensure that the back and side clearances are maintained. WARNING! Risk of Fire! Maintain specified air space clearances to combustibles. Inadequate air space could cause overheating and fire. DO NOT use screws more than 19mm in length on the lower access cover panel. Longer screws may penetrate gas line or damage valve or electrical components. Note: It is acceptable to use a high temperature silicone sealant to adhere plasterboard to lower access cover panel. The appliance is designed to be used with 13mm wall sheathing materials such as plasterboard, plywood, wood composites, or non-combustible materials. Thicker materials may be used. Refer to facing and finishing details in this manual. Facing Material • Facing and/or finishing materials must never overhang into the glass opening. • Facing materials may be combustible or non-combustible WARNING! Risk of Fire! DO NOT apply combustible materials beyond the minimum clearances. Comply with all minimum clearances to combustibles as specified in this manual. Overlapping materials could ignite and will interfere with proper operation. PAINTING If desired finishing includes a painted wall, 100% acrylic latex, oil-based or standard acrylic paints may be used. Follow paint manufacturer’s instructions for paint and primer application. 30mm 22mm 64mm 64mm 375mm 375mm SCREWS ONLY IN SHADED AREA City Series ACB40E |...

  • Page 38: Framing And Finishing Inset Installations

    installation Framing and Finishing Inset Installations 1. Frame in the enclosure for the unit with framing material. Note: When constructing the framed opening ensure there is access to install the gas lines,electrical. Also the wiring harness must be wall mounted using the receptacle provided with the appliance. The wiring harness will be located on the right hand side of the appliance if facing the unit from the front. This must be done prior to any finishing. Do not place any materials any- 2. F or exterior walls, insulate the enclosure to the same degree as the rest of where glass is located. the house, apply vapour barrier and plasterboard, as per local installation 13 mm codes. (Do not insulate the fireplace itself). WARNING: Failure to insulate and add vapor barriers to the inside of the exterior wall will result in operational and performance problems including, but not limited to: excessive condensation on glass doors, poor flame package, carbon, blue flames etc. These are not product related issues. Note that in all applications while there is a zero clearance to combustibles to the unit, all clearances to combustibles from the flueing inside the chase still applies. Please see flueing clearances in the specific product manual. 3. T o ensure the chase is sealed from the outside wall into the room, all joints on the facing wall MUST be sealed, mudded, and taped to finish.

  • Page 39: Tv Recessed Into Wall - Typical Installs

    installation TV Recessed into Wall - Typical Installs Maximum TV Recess TV Flush with Hearth ACB40E shown ACB40E shown City Series ACB40E |...

  • Page 40: Exterior Flue Termination Locations

    installation Exterior Flue Termination Locations FIGURE 6.2 (in part): LOCATION OF FLUE TERMINALS OF BALANCED FLUE AS/NZ 5601, ROOM-SEALED, FAN ASSISTED OR OUTDOOR APPLIANCE | City Series ACB40E...

  • Page 41: Clearances

    installation Clearances Minimum clearances (mm) Ref. Item Natural Fan Draught Assisted Below eaves, balconies and other projections: Appliances up to 50 MJ/h input Appliances up to 50 MJ/h input From the ground, above a balcony or other surface* From a return wall or external corner* From a gas meter (M) (see Note 5) (see Clause 5.11, 5.9 for vent terminal location of regulator) 1000 1000 (see Table 6.7 for New Zealand requirements) † From an electricity meter or fuse box (P) (see Note 5) From a drain or soil pipe Horizontally from any building structure* or obstruction facing a terminal From any other flue terminal, cowl, or combustion air intake Horizontally from an openable window, door, non-mechanical air inlet, or any other opening into a building iwth the exception of sub-floor ventilation: Appliances up to 150MJ/h input*...

  • Page 42: Wall Mount On / Off Switch And Battery Holder Installation

    installation Wall Mount On / Off Switch and Battery Holder Installation Required for all installations IMPORTANT INSTALLATION NOTE: The Battery Holder must be placed inside the supplied (Low Voltage) junction type wall box and installed into the wall only. DO NOT INSTALL WITHIN THE CONFINES OF THE FIREPLACE SWITCH MUST BE ACCESSIBLE Battery Holder Installation 1. Install the low voltage junction box to the framing, at desired location within 3m from fireplace. 2. F eed the 6 pin connector wiring harness through the opening at back of junction box. The wiring harness is located near the gas valve and will need to be routed to the exterior of the fireplace from either the left or right hand side prior to finishing.

  • Page 43: Flue Restrictor Position

    installation Flue Restrictor Position Flue restriction is required for certain flueing installations, see the diagrams in the "Flueing Arrangements" section to determine if they are required for your installation. The Flue Restrictor plate is packed in the instruction manual package. To set the flue restriction as indicated in the flueing arrangements diagrams, refer to the following instructions; 1. Remove the safety glass and firebox glass - see instructions in this manual. 2. Remove the screws that hold the flue restrictor plate in place (see Diagram 1) 3. Adjust the flue restrictor plate to the required flue restrictor position as per the diagrams shown. 4. Once the flue restrictor plate is in the required position, secure with screws. Flue Restrictor Positions Screw locations Set 0 (Full open) Factory set Flue restrictor location - inside top of firebox Diagram 1 Set 1 (Vent restrictor at 51mm) Set 2 (Vent restrictor at 44mm) Set 3 (Vent restrictor at 38mm) City Series ACB40E |...

  • Page 44: Flueing Arrangements Horizontal Terminations

    installation Flueing Arrangements Horizontal Terminations Flex Vent 102mm x 173mm These flueing systems, in combination with the ACV40E Direct Vent Gas Fireplace, have been tested and listed as a direct vent heater system. The location of the termination cap must conform to the requirements in the Vent Terminal Locations diagram in "Exterior Vent Termination Locations" section. Regency ® Direct Vent (Flex) System Termination Kits includes all the parts needed to install the ACV40E using a flexible vent. FPI Kit # Length Contains: #946-515 1.2m 175mm flexible outer liner (Kit length) 102mm flexible inner liner (Kit length) spring spacers...

  • Page 45: Flueing Introduction

    installation Flueing Introduction The ACB40E uses the "balanced flue" technology Co-Axial system. The inner liner flues products of combustion to the outside while the outer liner draws outside combustion air into the combustion chamber thereby eliminating the need to use heated room air for combustion and losing warm room air up the chimney. Note: These flue pipes must not be connected to any other appliance. The gas appliance and flue system must be flueed directly to the outside of the building, and never be attached to a chimney serving a separate solid fuel or gas burning appliance. Each direct flue gas appliance must use it's own separate flue system. Common flue systems are prohibited. Flueing Arrangement for Horizontal Terminations The diagram shows all allowable combinations of vertical runs with horizontal terminations, using one 90 (two 45 elbows equal one 90 elbow). Note: Must use optional rigid pipe adapter (Part# 510-994) when using Rigid Pipe Flueing Systems. (Metres) 1429mm "THIS UNIT MUST ALWAYS TERMINATE / FLUE DIRECTLY TO THE OUTDOORS." Flue RESTRICTOR SETTING: Flue restrictor factory set at Set 0. Refer to the "Flue Restrictor Position" section for details on how to change the flue restrictor from the factory setting of Set 0 to Set 2 if required.

  • Page 46: Horizontal Terminations

    installation Horizontal Terminations Rigid Pipe 102mm x 175mm The minimum components required for a basic horizontal termination are: 1 Horizontal Termination Cap 1 Rigid Pipe Adaptor (510-994) Horizontal 1 Wall Thimble Termination Cap 1 Length of pipe to suit wall thickness (see chart) Vinyl Siding Wall thickness is measured from the back standoffs to the inside mounting surface of termination cap. For siding other than vinyl Standoff (Optional) furring strips may be used, instead of the vinyl siding standoff, to create a level surface to mount the flue terminal. The Terminal must not be recessed into siding. Measure the wall thickness including furring strips.
  • Page 47 installation Horizontal Terminations Rigid Pipe 102mm x 175mm The diagrams below shows examples of horizontal termination arrangements using one, two, or three 90 elbows (two 45 elbows equal one 90 elbow) 1. A maximum of three 90 elbows are permitted. 2. Minimum distance between elbows is 305mm. • Maintain clearances to combustibles as listed in the "Clearances" section. • Horizontal flue must be supported every 0.9m. • Firestops are required at each floor level and whenever passing through a wall. • Must use optional rigid pipe adaptor (Part# 510-994) when using rigid pipe flue systems. • A flue guard should be used whenever the termination is lower than the specified minimum or as per local codes. • Flex system can only be used up to 3m - otherwise rigid flueing must be used. Horizontal Flueing with Two (2) 90 Elbows Horizontal Flueing with Three (3) 90 Elbows One 90 elbow = Two 45...

  • Page 48: Vertical Terminations

    installation Vertical Terminations Rigid Pipe 102mm x 175mm The minimum components required for a basic vertical Vertical Terminal termination are: 1 Vertical Termination Cap 1 Rigid Pipe Adaptor (510-994) 1 Ceiling Firestop 1 Flashing Storm Collar 1 Storm Collar 1 Length of pipe to suit wall thickness (see chart) Flashing Galvanized pipe is desirable above the roofline due to its higher corrosion resistance. Continue to add pipe sections through the flashing until the height of the flue cap meets the minimum height Ceiling Firestop requirements specified in table below or local codes. Note that for steep roof pitches, the vertical height must be increased. A poor draft, or down drafting can result from high wind conditions...

  • Page 49: Flueing Arrangement For Vertical Terminations

    installation Flueing Arrangement for Vertical Terminations Vertical Flueing with Straight Vertical Flueing and or with a max. of two (2) 90 Elbows (1 - 90 2 - 45 The shaded area in the diagram shows all allowable combinations of straight vertical and offset to vertical terminations, using two elbows, with Rigid Pipe Flueing Systems. Two 45 elbows equal to one 90 elbow. • Vent must be supported at offsets. • Minimum distance between elbows is 305mm. • Maintain clearances to combustibles as listed in the "Clearances" section.

  • Page 50: Vertical Terminations

    installation Vertical Terminations Rigid Pipe 102mm x 175mm • Two 45 elbows equal to one 90 elbow. Maximum of six 45 elbows allowed. • Flue must be supported at offsets. • Minimum distance between elbows is 305mm. • Maintain clearances to combustibles as listed in the "Clearances" section. • Horizontal flue must be supported every 0.9m. • Firestops are required at each floor level and whenever passing through a wall. • Must use optional rigid pipe adaptor (Part# 510-994 when using rigid pipe flue systems) Vertical Flueing with Three (3) 90 Elbows One 90 elbow = Two 45 elbows. Option H + H1 V + V1 With these options,...

  • Page 51: Unit Installation With Horizontal Termination

    installation 5. Assemble the desired combination of pipe and 7. Ensure that the pipe clearances to combustible Unit Installation with Horizontal elbows to the appliance adaptor and twist-lock materials are maintained (Diagram 3). Install Termination for a solid connection. the termination cap. 102mm x 175mm Flueing (Rigid Flue Systems) Note: For best results and optimum Note: If installing termination on a vinyl performance with each approved siding covered wall, a vinyl siding Minimum Flue Clearances f l u e i n g s y s t e m , i t i s h i g h l y standoff or furring strips must be...
  • Page 52 installation Unit Installation with Horizontal NOTE: Horizontal sections must be sup- ASTROCAP ported at intervals not exceeding DIMENSIONS (946-523/P) Termination 0.9 meter. (Flame picture and 102mm x 175mm Flueing performance will be affected by (Flex Flue Systems) sags in the liner). Minimum Flue Clearances 4. Separate the 2 halves of the wall thimble and to Combustibles...

  • Page 53: Duravent Vertical Termination

    installation 5. Cut an opening in the roof centered on the Dura-vent Vertical Termination small drilled hole placed in the roof in Step 2. 102mm x 175mm Flueing The hole should be of sufficient size to meet (Rigid Flue Systems) the minimum requirements for clearance to combustibles of 38mm. 1. Maintain the 38mm clearances (air spaces) to combustibles when passing through ceilings, walls, roofs, enclosures, attic rafter, or other nearby combustible surfaces. Do not pack Diagram 4 air spaces with insulation. Check "Flueing"...

  • Page 54: Vertical Termination-102 Mm X 175 Mm Flueing

    installation VERTICAL TERMINATION Vertical Termination 102mm x 175mm Flueing - Vertical Flex Flue Kit (946-755) 102MM X 175MM FLUEING - VERTICAL FLEX VENT KIT (946-755) Note: The roof fl ashing is not included with this kit and must be purchased separately.
  • Page 55 installation 13. Slide the fi nished length up towards the fl ashing ensuring the length of pipe is a minimum of 0.6m measured from the top of the roof. Level the chimney and secure using the roof support provided with kit to bottom side of the roof as shown using a minimum of 2 screws per side- see Diagram 3b.

  • Page 56: Vertical Flue Extension Kit

    installation VERTICAL FLUE EXTENSION KIT (APPROVED MODELS) Vertical Flue Extension Kit (Part #946-756) (PART # 946-756) 6.1m Flex pipe Extension CEILING FIRESTOP/FIRESTOP SPACER 100mm inner pipe 6.1m ( PART # 946-757) Used in conjunction with the 946-755 Vertical Flex kit for vertical installations or for horizontal installations when using the power vent option only where a Used in conjunction with the 946-755 Vertical flex kit and 946-756 kit Vertical maximum of 2 x 946-756 may be used up to a maximum of 12.2m.

  • Page 57: System Data

    installation Pilot Adjustment 885 S.I.T. Valve Description ACB40ENG SYSTEM DATA Min. Supply Pressure 1.13 kPa 1) 6 Stage flame adjustment Periodically check the pilot flames. Correct flame 2) Pilot adjustment pattern has two strong blue flames: 1 flowing Manifold Pressure High 0.96 kPa 3) Outlet Pressure Tap around the flame sensor and 1 flowing across Manifold Pressure Low 0.30 kPa 4) Inlet Pressure Tap...

  • Page 58: Wiring Diagrams

    installation Wiring Diagrams No electrical power supply is required for the gas (Do not cut the earth terminal off under any Caution: Ensure that the wires do not control to operate. 240 Volt AC power is needed circumstances.) touch any hot surfaces and are away from for the lights. sharp edges. Electrical power must be brought to the appliance by a licensed electrician. EARTH BLUE BLACK VARIABLE BATTERY LIGHTS CONNECTION CAUTION: Label all wires prior to disconnection when servicing controls.

  • Page 59: Optional Fan Ducting Kit Installation

    installation City Series 40 ACB40E Optional Fan Ducting Kit Installation OPTIONAL FAN DUCTING KIT INSTALLATION LISTINGS AND CODE GENERAL INFORMATION Maximum Duct Run: 9.0m Kit Contains 4.5m APPROVALS The Fan Kit increases the effectiveness of your fireplace by dispersing warm air from the fireplace If you require more than 4.5m please purchase Fan This Fan Kit has been approved for use with to remote locations in the same room or other...
  • Page 60 installation City Series 40 ACB40E OPTIONAL FAN KIT INSTALLATION NOTE: Installation of Fan Kit should be done prior Air Duct to installation of the wall. 2) Mount and secure the fan housing assembly to framing members, the front of the fan housing will protrude 12.7mm out of the wall so it may be finished with plasterboard, etc.

  • Page 61: Fan Duct Extension Kit

    City Series 40 ACB40E installation OPTIONAL FAN KIT INSTALLATION Fan Duct Extension Kit FAN DUCT EXTENSION KIT In order to use the fan extension duct kit, you must have fan kit. This kit allows you to extend the fan duct to 9m. 2.

  • Page 62: Inner Glass Panel (Firebox Glass) Installation / Removal

    installation Inner Glass Panel (Firebox Glass) Installation / Removal To watch the firebox installation video click here http://bit.ly/2upQQ3W Note: glass panels must be installed to operate fireplace Push side glass WARNING: GLASS HANDLING panel firmly to back wall We recommend using the glass vacuum holders supplied by the manufac- until springs are turer. Lower the glass to rest in a safe place, this is to prevent damage to the compressed— glass edges. Extra care must be taken when removing/installing the glass. then close Breakage or damage to the edge of the glass which occurs as a result of clamps. careless handling will not be covered under warranty. • W e recommend handling the glass with supplied vacuum clamps •...
  • Page 63 installation 5. E nsure all 7 front clamps are in the open position to allow clearance for Note: Ensure that the front glass is centered and evenly spaced with side glass the glass. (3 sided unit) - open to release glass clamps to remove from surface of glass. Open clamps prior to plac- ing front glass panel ACB40E shown Open clamps to release pressure on 6. L ift up the front panel using the supplied vacuum clamps and position into the springs the lower front channel–ensure the front panel is accurately centered—with the front panel in position—secure in place by closing the 3 lower clamps and 4 upper clamps. 7. F or 3 sided and corner units only: Return to the side panel(s), and release the upper and lower clamps. The springs will release and push the glass Press glass vacuum clamps in open position firmly onto surface of glass. Bring side panel forward slightly—this will create a seal between the front and...

  • Page 64: Outer Safety Glass Panel (Barrier Glass) Installation / Removal

    installation Outer Safety Glass Panel (Barrier Glass) Installation / Removal To watch the safety barrier glass installation video click here http://bit.ly/2upQQ3W Note: safety glass panels must be installed to operate fireplace 3. T ilt the top of the glass panel inward and lift up and underneath the upper front panel of the outside frame. Hook the glass panel WARNING: GLASS HANDLING onto the pins and also onto the two angle adjustment brackets lo- cated on the frame in two locations as shown in the diagram below.
  • Page 65 installation Outer Safety Glass Panel (Barrier Glass) Installation / Removal Note: safety glass panels must be installed to operate fireplace Note: A fter the side panel has been adjusted so it is installed at 90º to the 4. F or 3 sided and corner units only: With front panel installed, proceed to install the side panel(s). unit and not flaring in or out, check to ensure there is no gap between I dentify the left and right side panels before installing. Facing the front of the front and side panel. If there is a gap as shown below, slide the side the unit, the right panel will show an arrow pointing to the front of the unit panel to adjust the position and close the gap. as shown in the diagram below. Direction arrow on side panel bracket, should point toward front of unit 5. Lift up the side panel with the supplied glass clamps (see procedure on previous page). Tilt the side of the glass panel inward and lift up and under-...

  • Page 66: Propane/Ulpg Conversion Instructions

    installation CITY SERIES Propane/ULPG Conversion Instructions CONVERSION FROM NG TO LP/ULPG Using SIT 885 NOVA Gas Valve THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION! WARNING 6. If unable to access this Cable - undo 2 screws securing the IFC Board and slide out of unit to access cable.
  • Page 67 CITY SERIES installation 11. Loosen 4 screws in locations shown below (2 at front and 2 at rear)—slide burner to the left away from the orifice and lift out. front screw locations 14. Unscrew the pilot orifice with the allen key; then replace with the LPG pilot orifice and the pilot cap, provided in the kit.

  • Page 68: Painted Panel Installation

    installation CITY SERIES Painted Panel Installation Inner Panels Outer Panels CB40E OUTER PANELS CB40E INNER PANELS The ACB40E can be equipped with optional steel inner panels— 3 outer The CB40E can be equipped with optional steel inner panels. panels and 2 inner panels. Note: Install inner safety glass prior to installation of outer panels-see CB40E - 3 outer panels and 2 inner panels. instructions in manual Turn off unit and allow to cool to room temperature.

  • Page 69: Enamel Panel Installation

    CITY LINE installation CB40E ENAMEL PANEL INSTALLATION Enamel Panel Installation Black Enamel Panels — Handling Instructions • Black Enamel panels must be inspected for scratches and dimples prior to installation. All claims to be recorded at this time. Claims for damage after installation will not receive consideration. •...

  • Page 70: Burner And Firebox Media Options

    installation Burner and Firebox Media Options Spread the media evenly over the burner. Ensure the glass/stones do not overlap excessively as this will affect the flame pattern. IMPORTANT NOTE: Only the supplied approved media are to be used with these fireplaces. Use of any other type of glass or stones can alter the unit's performance. Any damage caused by the use of any unapproved glass or stones will not be covered under warranty. When using Ceramic Spa/Volcanic Stones ensure required glass crystals/beads are used as a base. DO NOT overstack Ceramic Spa Stones or Volcanic Stones on burner or in the pilot area. Media must be installed on and around burner only in amounts noted below. ACB40E Approved Media* Where Used Quantity Fireglass (starfire, copper or black) On burner 454g Glowing embers/sea wool (supplied with unit) On burner 1 bag Natural Stones Around burner 1 box = 6.8kg Ivory Natural Stones Around burner 1 box = 6.8kg 19mm Crushed black glass Around burner 1.6kg Crushed Iceburg chips Around burner 1.6kg * Media not supplied with unit - must be purchased separately. Natural / Ivory Stones + Fireglass 19mm Crushed black glass + Black Fireglass Starfire Fireglass + Iceburg chips...

  • Page 71: Optional Driftwood Log Set Installation

    CITY LINE installation Optional Driftwood Log Set Installation CITY LINE - LOG INSTALLATION Read the instructions below carefully and refer to the images. If the logs are broken do not use the unit until they are replaced. Broken logs can interfere with pilot operation. Improper positioning of the logs may create carbon build-up and can alter the unit's performance which is not covered under warranty.
  • Page 72 CITY LINE installation 8. Place the split end of Log 3 to the right front corner of the burner—angle Rest the other end of Log 4 on the indent in Log 2 as shown below. the log so that the other end is sitting approximately 13mm from the edge of the burner tray.

  • Page 73: Operating Instructions

    operating instructions First Fire Normal Operating Sounds Of Aeration Adjustment Gas Appliances The burner aeration is factory set but may need The FIRST FIRE in your fireplace is part of the paint adjusting due to either the local gas supply or curing process. T o ensure the paint is properly cured, It is possible that you will hear some sounds from altitude. Open the air shutter for a blue flame or it is recommended you burn your fireplace for at your gas appliance. This is perfectly normal due to close for a more yellow flame.

  • Page 74: Maintenance

    maintenance 3. Check for evidences of excessive condensation, Maintenance Instructions Glass Replacement such as water droplets forming in the inner liner, and subsequently dripping out the joints, In the eflue that you break your glass by impact, 1. Always turn off the gas valve before cleaning. Continuous condensation can cause corrosion purchase your replacement from an authorized For relighting, refer to lighting instructions. Keep of caps, pipe, and fittings. It may be caused Regency dealer only. Replacement glass is shipped the burner and control compartment clean by by having excessive lateral runs, too many already installed into the door frame. Reinstall as per brushing and vacuuming at least once a year.

  • Page 75: Bulb Replacement

    maintenance Bulb Replacement 1. T urn off unit and allow to cool to room temperature. 4. Loosen 2 screws on each side of individual inner light cover and remove. 2. R emove outer safety glass panels and inner panels (firebox glass)–see 5. R emove glass cover by using a flat head screwdriver to pry the tab securing instructions in this manual. the glass assembly in place. 3. L oosen 2 outer screws on each side to remove outer light cover — located 6. Replace bulb and reverse steps to complete procedure. in the upper inside front of the firebox and remove. NOTE: D o not handle bulb with bare hands. Use packaging or a tissue to hold new bulb when replacing. Regency Part# Oven Lamp Assembly G9 240V/25W Regency Part# Replacement Bulb G9 240 Volt/25 watt City Series ACB40E |...

  • Page 76: Valve Replacement

    maintenance Valve Replacement 7. Remove 16 screws in locations shown below. Important: Always shut off gas supply/240 volt power prior to servicing the gas valve. 1. T urn off unit and allow to cool to room temperature. 2. R emove outer enamel or steel panels—see instructions in the panel removal section in this manual 3. R emove outer safety glass panels and inner panels (firebox glass)–see instructions in this manual. 4. Remove all media and logs (if installed) — set aside. 5. Remove inner base panel. Inner base panel Remove 16 screws securing valve tray 8. L ift valve tray out partially and disconnect flexible gas connection on the valve inlet side, remove valve tray- replace with new valve tray.

  • Page 77: Main Assembly

    parts list Main Assembly 905-039 Burner Orifice #54 ULPG 904-606 Fitting 90 Street Elbow Extruded 657-525 Burner Assembly - NG/LP 904-165 Fitting 3/8 Male Flarex Mpt Strt Adaptor 656-046 Pilot Cover/Shield W840470 Pilot Assembly Gasket 904-996 Burner Orifice 2.40 mm (PO512) 656-040 Valve Assembly Gasket 656-039 Burner Orifice Mount Gasket 911-276 Burner Orifice #53 LP (PO512) 911-299 Remote Control GTMFL CE SIT 0.584.052 911-006 Pilot Assembly IPI NG 2 Flame 911-187 Remote Receiver/Battery Holder 584.103 911-277 Pilot Assembly IPI LP 2 Flame 910-576 Cover Wall Mount White GTM SIT 0.584.803 657-009 IFC Cover/Shield 911-173 Wire Harness IFC No CPI Switch 584.924 911-298 IFC Board SIT Proflame II CE 0.584.316 911-177 Wire 4 Position IFC Fan & Light 911-188...
  • Page 78 parts list 656-991 Chase Flue Front Black 656-950 Chase Steel Framing Kit (Compact) 656-995 Adaptor Heat Wave 656-951 Extended Chase Steel Framing Kit 946-591 Heatwave Fan Kit 656-952 Extended Hearth Steel Framing Kit 946-675 Fireglass Black Reflective 6mm /454g Pkg 656-992 Chase Flue Sides Black 946-676 Fireglass Copper 6mm /454g Pkg 656-917* Inner Panel Black (Painted) 946-677 Fireglass Starfire 6mm /454g Pkg Sold only as a complete set 946-780 Crushed Glass Coal Black mm / 1.6kg 657-991 Chase Flue Flush Front White 946-710 Volcanic Stones Black & Gray 946-711 Volcanic Stones Ivory & Tan | City Series ACB40E...
  • Page 79 parts list City Series ACB40E |...

  • Page 80: Warranty

    warranty Limited Lifetime Warranty FPI Fireplace Products International Ltd. (“the manufacturer”) through its wholly owned subsidiary, Fireplace Products Australia Pty Ltd (for Australia and New Zealand customers) and sold under the Regency® brand of fireplace products (collectively referred to herein as “FPI”), extends this Limited Lifetime Warranty to the original purchaser of this appliance provided the product remains in the original place of installation.
  • Page 81 warranty part is returned to the distributor, dealer or agent for inspection if requested by FPI. Alternatively, FPI may at its own discretion fully discharge all of its obligations under the warranty by refunding the verified purchase price of the product to the original purchaser. The purchase price must be confirmed by an original copy of the tax invoice. The authorised selling dealer, or an alternative authorised FPI dealer if pre-approved by FPI, is responsible for all in-field diagnosis and service work related to all warranty claims.
  • Page 82 warranty FPI has no obligation to enhance or modify any unit once manufactured (i.e. as products evolve, field modifications or upgrades will not be performed on existing appliances). Any unit showing signs of neglect or misuse will not be covered under the terms of this warranty policy and may void this warranty.
  • Page 83 warranty Limitations of Liability: 1. Exclusion of implied terms The customer may have the benefit of consumer guarantees under the Australian Consumer Law. To the maximum extent permitted by law, all terms, conditions or warranties that would be implied into this Warranty or in connection with the supply of any goods or services by the supplier under law or statute or custom or international conventions are excluded.
  • Page 84 warranty Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase.
  • Page 85 notes City Series ACB40E | | City Series ACB40E-11...
  • Page 86 notes | City Series ACB40E...
  • Page 87 Installer: Please complete the following information Dealer Name & Address: _________________________________________ ______________________________________________________________ Installer: ______________________________________________________ Phone #: ______________________________________________________ Date Installed: __________________________________________________ Serial No.: _____________________________________________________ Printed in Canada Regency and City Series are trademarks of FPI Fireplace Products International Ltd. © Copyright 2019, FPI Fireplace Products International Ltd. All rights reserved.
