AES global CellCOM PRIME Installation & User's Instructions page 36

Auxiliary Device Relay Setup
Relay 3
ON DIP
1 2 3 4
Relay 6
ON
DIP
1 2 3 4
24V 1 2 3
NC COM
1
SLAV E IN
SLAV E OUT
1 2
COI L
A keypad does not have dip switches.
To assign the relay number use the
keypad keys as follows.
P a g e | 36
Relay 4
ON
DIP
1 2 3 4
Relay 7
ON
DIP
1 2 3 4
ON
DIP
1 2 3 4
NO PTE
2 3
3
Relay 5
5
ON
DIP
1 2 3 4
Dip switch configuration for
relays 3 to 8 on auxiliary
Relay 8
devices.
ON
DIP
1 2 3 4
The sounder boards
set the relay number for
auxiliary unit
The dip switch of the prox must
match the dip switch configuration
of the auxiliary it wants to trigger
1 2 3
4 5 6
7 8 9
* 0 #
dip switches
it is in.
*#91#RelayNumber#
(Relay Number = 3-8)
