Architectural Model
Microphone (10)
Security Screw
Access
Waterproof Mylar
1.5W Speaker (9)
Optional
Illuminated
Keypad. (14/15)
Mounting Holes
Optional Keypad
(14/15) & PROX (11)
Call Button (5/6)
Optional PROX
Coil (11)
P a g e
| 13
Module
Side Illumination
(12/13)
DDA LED's
(PROX version only)
Optional PROX
Reader (11)
Illuminated IP67
Push Button (5/6)
Side Illumination Board (12/13)
Cable Entry Hole
GSM Assembly (2)
