AES global Imperial 703 DECT Manual

703 DECT
* ALWAYS RANGE TEST THE UNIT ON SITE BEFORE INSTALLATION *

WIRING DIAGRAM

Shield/Filter
LIGHTNING PRONE AREAS Drain Cable
MUST USE SURGE PROTECTION
FOR POWER SUPPLY!
Transmitter Module
WARNING:
ESD SENSITIVE
Code
Button
Optional
Antenna
Pairing
LEDs
RELAY RELAY
24V
2 1
AC DC
IN
SUFFICIENT POWER CABLE FOR
To Gate Controller CALLPOINT REQUIRED ( 2x1mm
N/ O | C | N/ C
24V AES Power Supply
RELAY 1
Did you know?
With our 703 DECT audio system you can
add up to a max of 4 portable handsets or
wall mounted versions.
(1 DEVICE WILL RING PER BUTTON)
- Imperial Intercom System
KEEP SHORT
( 8m MAX! )
+
-
12V
OUT
1
2
3
4
NOTE: Wiring method will
COM C
change depending on
amount of buttons on
faceplate.
See provided supplement guide for
more info.
BUTTON 2
= COMMON
Optional Programmable Keypad
THE AES KEYPAD IS AN OPTIONAL EXTRA.
IF KEYPAD PRESENT, PLEASE SEE '
FOR FULL INSTRUCTIONS ON PROGRAMMING AND
EXTENSIVE FEATURES.
2
)
Link both Relay 1's to
allow either to release the
N/ C | C |
same door / gate.
RELAY 1
NEED MORE ASSISTANCE?
Please scan this QR Code to be
brought to our Resources page
where you can find all of our
guides and available resources.

SITE SURVEY

AES KP will come pre-
wired to the CallPoint
TIP:
You must test to ensure that the system is capable of operating across the desired
+24V-
+ -
range. Power the system on and place the handsets in their expected locations
around the property to ensure that the system is fully functional and suitable for
Insert Drain Cable into
the site.
0v (-) on Power IN
OPTIMAL RANGE
TIP:
property and near a window if possible. Also ensure the transmitter is mounted
pointing towards the handset.
Concrete walls can reduce the normal open-air range of up to 400 metres/yards
BUTTON 4
by

POWER CABLE

BUTTON 3
TIP:
to power the unit.
BUTTON 1
Please use the following cable:
Up to 2 metres ( 6 feet )
COM
Up to 4 metres ( 12 feet ) – Use minimum 0.75mm
Up to 8 metres ( 24 feet ) – Use minimum 1.0mm
KPX1200 GUIDE
'
GROUND
N/ O
TRANSMITTER
+ - DA TA EG
N.C. COM N.O. N.C. / N.O. I/O
IN
24v IN RELAY 1 R2 EGRESS
RELAY CONNECTIONS
N/ O Normally Open
C Common
N/ O
N/ C Normally Closed
Find all of our support options such as Web Chat,
Full Manuals, Customer Helpline and more on
RESTOCKING FEES MAY APPLY IF RETURNED AFTER INSTALL DUE TO SITE
It is recommended that the system be fully tested on site
SYSTEM INCOMPATIBLE WITH FOIL INSULATION.
For longer range installations, locate the handset closest to the front of the
30-50% per wall.
KEEP POWER SUPPLY AS CLOSE AS POSSIBLE.
Most technical calls received are due to installers using CAT5 or alarm cable
NEITHER are rated to carry enough power! ( 1.2amp peak )
– Use minimum 0.5mm

MAGNETIC LOCK EXAMPLE

Follow this method when using a magnetic lock. If the relay in either the
| C | N/ C
Transmitter or optional AES Keypad is triggered it will temporarily lose power
and allow the door/gate to release.
For installs without the optional AES Keypad; connect the
Magnetic Lock PSU to N/C terminal on Transmitter Relay.
+
MAX 24 VOLTS!
-
POWER ADAPTER
EXIT
* MAGNETIC LOCK PSU SOLD SEPARATELY *
+
MAGNETIC LOCK
-
STILL HAVING TROUBLE?
our website:
WWW.AESGLOBALONLINE.COM
ISSUES. PLEASE SEE FULL T&C'S ON OUR WEBSITE.
