Ensure SIM is activated.
Pre-pay SIM will need credit first.
Perform a final check of wiring and ensure the antenna is connected before switching on the
power. Once the power is switched on, the power LED should illuminate.
preferred
absolute max!
Pre-wired in iGate
Door/gate limit switch
(to allow remote checking
of door position)
When the exit button is pressed it will trigger relay 1 for the pre-programmed time in the
app. (Default is 1 second)
P a g e | 33
Inserting the SIM card
Powering Up
24V dc
28V ac
Exit Button (PTE)
45 chamfer IN
Pads DOWN
WARNING
Ensure power is OFF. Do not hot
insert or remove while power on
Pre-wired to internal call
button *Not on iGate
Push to exit
button
(triggers relay 1)
.
