Technical Specifications - AES global CellCOM PRIME Installation & User's Instructions

GENERAL
Front Panel
Hood Cover (MOD, IMP(K),
PED)
Mounting Housing (Backbox)
Mounting Type
Call Button
Power Supply
Power Consumption
Solar Power
Ingress Protection:
Approvals
Dimensions
Operating Temperatures
KEYPAD MODULE
Backlighting
P a g e | 21

Technical Specifications

Portrait Orientation
AB/ABK = 3mm Acrylic on Architectural Design Marine Grade
Stainless Steel BS316 Front Plate
AS/ASK = 3mm Marine Grade Stainless Steel BS316 on
Architectural Design Marine Grade Stainless Steel BS316 Front
Plate
FS/FSK = Flush Design Marine Grade Stainless Steel BS316 Front
Plate
IMP/IMPK = 3mm Acrylic on Imperial Design Marine Grade
Stainless Steel BS316 Front Plate
Landscape Orientation
PED = Pedestal Surface Mount. Powder Coated Marine Grade
Stainless Steel BS316 Front Plates with 3mm Acrylic on Design
Marine Grade Stainless Steel BS316 Modular Plates
Powder coated Aluminium
Marine Grade Stainless Steel BS316
AB/AS/ABK/ASK = Surface-Mounted with backlighting,
IMP/IMPK = Surface-Mounted,
FS/FSK = Flush-mounted
Stainless-steel button with illuminated LED Ring (max. 4
separate buttons)
24V DC
GSM PCB w/Keypad & Prox
Standby Current: 80mA
Dial Out: 300mA
Max Current: 2A
30Watt Solar Panel (minimum)
2x 12V 10AH Batteries connected in series to provide 24V
output. The power output must be regulated.
IP55
FCC, CE
See catalogue
-25 to +55°C / -13 to 131°F
Blue / White
