AES global 603 DECT Manual

603 DECT
* ALWAYS RANGE TEST THE UNIT ON SITE BEFORE INSTALLATION *
WIRING DIAGRAM
Shield/Filter
LIGHTNING PRONE AREAS Drain Cable
MUST USE SURGE PROTECTION
FOR POWER SUPPLY!
Transmitter Module
WARNING:
ESD SENSITIVE
Code
Button
Optional
Antenna
Pairing
LEDs
RELAY
RELAY 24V
1
2 AC DC
IN
To Gate Controller CALLPOINT REQUIRED ( 2x1mm
N/ O | C | N/ C
RELAY 1
Did you know?
With our 603 DECT audio system you can
add up to 4 portable or wall mounted audio
handsets.
( ALL DEVICES WILL RING ON EACH CALL. )
- Radio Intercom System
KEEP SHORT
( 8m MAX! )
+
-
12V
OUT
1
2
3
4
C
SUFFICIENT POWER CABLE FOR
2
)
Link both Relay 1's to allow
either to release the same
24V AES Power Supply
door / gate.
NEED MORE ASSISTANCE?
Please scan this QR Code to be
brought to our Resources page
where you can find all of our
guides and available resources.
AES KP will come
pre-wired to the
CallPoint
+ - +24V-
Insert Drain Cable into
0v (-) on Power IN
AES KEYPAD
THE AES KEYPAD IS
AN OPTIONAL
EXTRA.
PLEASE SEE
'KPX1200 GUIDE'
FOR FULL
INSTRUCTIONS ON
PROGRAMMING
AND EXTENSIVE
FEATURES.
RELAY 1 R2
RELAY CONNECTIONS
N/ O Normally Open
C Common
N/ C | C | N/ O
N/ C Normally Closed
RELAY 1
Find all of our support options such as Web Chat,
SITE SURVEY
RESTOCKING FEES MAY APPLY IF RETURNED AFTER INSTALL DUE TO SITE
TIP: It is recommended that the system be fully tested on site
You must test to ensure that the system is capable of operating across the desired
range. Power the system on and place the handsets in their expected locations
around the property to ensure that the system is fully functional and suitable for
the site.
OPTIMAL RANGE
TIP: For longer range installations, locate the handset closest to the front of the
property and near a window if possible. Also ensure the transmitter is mounted
pointing towards the handset.
Concrete walls can reduce the normal open-air range of up to 400 metres/yards
by 30-50% per wall.
POWER CABLE
TIP: Most technical calls received are due to installers using CAT5 or alarm cable
to power the unit.
NEITHER are rated to carry enough power! ( 1.2amp peak )
Please use the following cable:
Up to 2 metres ( 6 feet ) – Use minimum 0.5mm
Up to 4 metres ( 12 feet ) – Use minimum 0.75mm
Up to 8 metres ( 24 feet ) – Use minimum 1.0mm
MAGNETIC LOCK EXAMPLE
Follow this method when using a magnetic lock. If the relay in either the
N/ O | C | N/ C
Transmitter or optional AES Keypad is triggered it will temporarily lose power
TRANSMITTER and allow the door/gate to release.
For installs without the optional AES Keypad; connect the
Magnetic Lock PSU to N/C
+
MAX 24 VOLTS!
-
POWER ADAPTER
EXIT
* MAGNETIC LOCK PSU SOLD SEPARATELY *
+
MAGNETIC LOCK
-
STILL HAVING TROUBLE?
Full Manuals, Customer Helpline and more on
our website:
WWW.AESGLOBALONLINE.COM
ISSUES. PLEASE SEE FULL T&C'S ON OUR WEBSITE.
BEFORE installation.
SYSTEM INCOMPATIBLE WITH FOIL INSULATION.
KEEP POWER SUPPLY AS CLOSE AS POSSIBLE.
2 ( 18 gauge )
2
( 16 gauge )
2
( 14 / 16 gauge )
N/ C | C | N/ O
AES KEYPAD
POSITIVE of the
