5.9.4.
WAN
ETHERNET
Port M i rroring Setti ng :
SourcePort = Port 2
Desti nati onPort = Port 5
VT2
INSTALLATION MANUAL APRESA

VoIP topology 2

PBX/ VoIP PBX/ VoIP
IT SP GAT EWAY IT SP GAT EWAY
Port mirroring sw itch
1
T el ephone T el ephone
INTERNAL AND EXTERNAL CALLS ARE RECORDED
COPYRIGHT © 2011-2017 VIDICODE ®
RT P
M IRROR
2 3 4 5
T el ephone T el ephone
NIC
DWG-1148_00
