The Black 19" Housing; Front Side, Door Closed - Vidicode APRESA Series Installation Manual

2.1.

The BLACK 19" housing

(this model is obsolete)

Front side, door closed

HANDLE
BAR
2X USB 2.0
(NOT USED)
Front side, door opened
NUM LOCK BUTTON
(NOT USED)
INSTALLATION MANUAL APRESA
VENTILATON
POW ER LED
RESET
BUTTON
POW ER
SW ITCH
COPYRIGHT © 2011-2017 VIDICODE ®
LOCK
S ilver Line Call R ecor der
Apr esa
vidicode
HARD DISC
ACTIVITY LED
NUM LOCK LED
(NOT USED)
DVD
RE S E T
P OW E R
H.D.D
KB-LK
KB-LK
1
0
DOOR (OPENED)
HANDLE
DOOR
DWG1 130 _01
DVD
DWG1131_0
BAR
13
