6.1.2

Using the XE EDP Command

The XE EDP command can be used to remotely query
the for the error conditions shown on the
Tracer AV
front panel. The XE command returns two 5-digit
numbers in the format:
xxxxx yyyyy
where contains a decimal representation of any
xxxxx
existing error conditions as described in Table 6-2.
If more than one error condition exists, the number
returned is the sum of the values representing the error
conditions. For example, if the XE command returns
the number 1040, this value represents the sum of an
A/D reference error (1024) and an A/D calibration
checksum error (16).
The second number returned (
assignments as shown in Table 6-2 to indicate whether
the test for the error condition was run. For example,
the value = 50815 represents the decimal
yyyyy
equivalent of the binary value 1100 0110 0111 1111.
Using the bit assignments in Table 6-2, this value
indicates all tests were run.
Error
Code Description
0x0001 EEPROM Error
0x0002 Virgin EEPROM
0x0004 Config Parameter Checksum 0000 0000 0000 0100
Load Cell Checksum
0x0008
0x0010 A/D Calibration Checksum
0x0020 Print Formats Checksum
0x0040 XA Internal RAM Error
External RAM Error
0x0080
0x0100 Reserved
0x0200 ADC Physical Error
0x0400 ADC Reference
0x0800 Count Error
0x1000 Reserved
0x2000 Display Range
0x4000 ADC Range
0x8000 Gross Limit
0x10000 - 0x80000000
Table 6-2. Error Codes Returned on XE Command
) uses the same bit
yyyyy
Binary Value
0000 0000 0000 0001
0000 0000 0000 0010
0000 0000 0000 1000
0000 0000 0001 0000
0000 0000 0010 0000
0000 0000 0100 0000
0000 0000 1000 0000
0000 0001 0000 0000
0000 0010 0000 0000
0000 0100 0000 0000
0000 1000 0000 0000
0001 0000 0000 0000
0010 0000 0000 0000
0100 0000 0000 0000
1000 0000 0000 0000
Reserved
6.2

Status Messages

Two EDP commands, P and ZZ, can be used to
provide status about the
are described in the following sections.
6.2.1

Using the P EDP Command

The P EDP command returns the current displayed
weight value to the EDP port, along with the units
identifier. If the indicator is in an underrange or
overload condition, the weight value is replaced with
(overload) or
&&&&&& ::::::
6.2.2

Using the ZZ EDP Command

The ZZ EDP command can be used to remotely query
which annunciators are currently displayed. The ZZ
command returns the currently displayed weight and a
decimal number representing the LED annunciators
currently lit. The format of the returned data is:
wwwwww uu zzz
where is the current displayed weight and
wwwwww uu
units, is the annunciator status value (see
z z z
Table 6-3). If more than one annunciator is lit, the
second number returned is the sum of the values
representing the active annunciators.
If the annunciator status value returned on
Example:
the ZZ command is 145, the gross, standstill, and lb
annunciators are lit. 145 represents the sum of the
values for the standstill annunciator (128), gross mode
annunciator (16), and the lb/primary units annunciator
(1).
Decimal
Value
1 lb/primary units
2 kg/secondary units
16 Gross
32 Net
64 Center of zero
128 Standstill
Table 6-3. Status Codes Returned on the ZZ Command
Tracer AV Installation Manual - Appendix
Tracer AV . These commands
(underrange).
Annunciator
33
