FORMAT Menu
Parameter Choices
Level 3 submenus
Primary Units (PRIMAR Parameter)
DECPNT 88888.8
888888
888880
8.88888
88.8888
888.888
8888.88
DSPDIV 5D
1D
2D
UNITS LB
KG
OZ
TN
T
G
NONE
Secondary Units (SECNDR Parameter)
DECPNT 88888.8
888888
888880
8.88888
88.8888
888.888
8888.88
DSPDIV 5D
1D
2D
UNITS KG
OZ
TN
T
G
NONE
LB
MULT 0.453592
Enter other
choices via
keyboard
16 Tracer AV Installation Manual
Decimal point location. Specifies the location of the decimal point or dummy zeroes in the
primary unit display. Value should be consistent with local legal requirements.
Display divisions. Selects the minimum division size for the primary units displayed weight.
Specifies primary units for displayed and printed weight. Values are: LB=pound;
KG=kilogram; OZ=ounce; TN=short ton; T=metric ton; G=gram
NOTE: Indicators sold outside North America are configured with KG for both
primary and secondary units.
Decimal point location. Determines the location of the decimal point or dummy zeros in
the secondary unit display.
Display divisions. Selects the value of minimum division size of the displayed weight.
Specifies secondary units for displayed and printed weight. Values are: KG=kilogram;
OZ=ounce; TN=short ton; T=metric ton; G=gram; LB=pound.
Multiplier. Specifies the conversion factor by which the primary units are multiplied to
obtain the secondary units. The default is 0.453592, which is the conversion factor for
changing pounds to kilograms. See Section 6.5 on page 36 for a list of multipliers.
NOTE: Multipliers are pre-configured within the indicator. Manual entry is only
necessary when NONE is selected under UNITS.
To toggle between primary and secondary units, press the Units key.
Table 3-5. Format Menu Parameters (Continued)
Description
