Format Menu - Rice Lake REVOLUTION Tracer AV Installation Manual

3.2.3

Format Menu

DEFCAL CONFIG XXXXXXX FORMAT
PRIMAR
DECPNT DSPDIV
88888.8
88888. 8
888880
8.88888
88.8888
888.888
8888.88
FORMAT Menu
Parameter Choices
Level 2 submenus
PRIMAR DECPNT
DSPDIV
UNITS
SECNDR DECPNT
DSPDIV
UNITS
MULT
DSPRAT 250MS
500MS
750MS
1SEC
1.5SEC
2SEC
2.5SEC
3SEC
4SEC
6SEC
8SEC
CALIBR SERIAL PROGRM
SECNDR
UNITS DECPNT
5D
LB
88888.8
1D KG
888888
OZ
2D 888880
TN
8.88888
T 88.8888
G 888.888
8888.88
NONE
Figure 3-6. Format Menu
Specifies the decimal position, display divisions, and units used for the primary units. See
Level 3 submenu parameter descriptions.
Specifies the decimal position, display divisions, units, and conversion multiplier used for
the secondary units. See Level 3 submenu parameter descriptions.
Display rate. Sets the update rate for displayed values. Values are in milliseconds (MS) or
seconds (SEC).
Table 3-5. Format Menu Parameters
XXXXXXX SETPNT VERS
DSPDIV UNITS MULT
5D
KG
0.453592
OZ
1D
number
TN
2D
Only used if
UNITS =NONE
T
G
NONE
LB
Description
Tracer AV Installation Manual - Configuration
