Reporting Commands; The Resetconfiguration Command; Parameter Setting Commands; Soft Reset - Rice Lake REVOLUTION Tracer AV Installation Manual

5.1.2

Reporting Commands

Reporting commands (see Table 5-2) send specific
information to the EDP port. These commands can be
used in both setup mode and normal mode.
Command
DUMPALL List all parameter values
VERSION Tracer AV
P Write current displayed weight with units
identifier. See Section 6.2 on page 33 for
more information.
ZZ Write current weight and annunciator
status. See Section 6.2 on page 33 for
more information.
S Write one frame of stream format. See
Table 5-12 on page 30 for information
about the SX and EX commands.
Table 5-2. EDP Reporting Commands
5.1.3

The RESETCONFIGURATION Command

The
RESETCONFIGURATION
restore all configuration parameters to their default
values. Before issuing this command, the
must be placed in test mode (press and hold setup
switch for approximately three seconds to show TEST
menu).
This command is equivalent to using the DEFLT
function on the TEST menu. See Section 6.7 on
page 39 for more information about test mode and
using the TEST menu.
NOTE: All load cell calibration settings are lost when the
RESETCONFIGURATION command is run.
Command
DEFCAL Default Calibration
GRADS Graduations
ZTRKBND Zero track band
ZRANGE Zero range
MOTBAND Motion band
OVRLOAD Overload
SMPRAT Sample rate
DIGFLTR1 Digital filtering
DIGFLTR2
DIGFLTR3
DFSENS Digital filter cutout sensitivity
DFTHRH Digital filter cutout threshold
TAREFN Tare function
Function
software version
command can be used to
Tracer AV
Description
Table 5-3. CONFIG EDP Commands
5.1.4

Parameter Setting Commands

Parameter setting commands allow you to display or
change the current value for a particular configuration
parameter (Tables 5-3 through 5-11).
Current configuration parameter settings can be
displayed in either setup mode or normal mode using
the following syntax:
command<ENTER>
Most parameter values can be changed in setup mode
only. Use the following command syntax when
changing parameter values:
command=value<ENTER>
where is a number or a parameter value. Use no
value
spaces before or after the equal (=) sign. If you type an
incorrect command or value, the display reads
Changes to the parameters are saved as they are
entered but typically do not take effect until you exit
setup mode.
For example, to set the motion band parameter to 5,
type the following:
MOTBAND=5D<ENTER>
5.1.5

Soft Reset

The command will reset the
RS
losing configuration and calibration. It does reset
consecutive number.
300lb, 500lb
1–100 000
OFF, 0.5D, 1D, 3D
1.9%, 100%
1D, 2D, 3D, 5D, 10D, 20D, OFF
FS+2%, FS+1D, FS+9D, FS
15HZ, 30HZ, 60HZ, 7.5HZ
1, 2, 4, 8, 16, 32, 64
2OUT, 4OUT, 8OUT, 16OUT, 32OUT, 64OUT, 128OUT
NONE, 2DD, 5DD, 10DD, 20DD, 50DD, 100DD, 200DD, 250DD
BOTH, NOTARE, PBTARE, KEYED
Tracer AV Installation Manual - EDP Commands
Tracer AV without
Values
.
??
27
