SERIAL Menu
Parameter Choices
Level 2 submenus
EDP BAUD
BITS
TERMIN
EOLDLY
ECHO
Level 3 Submenus
BAUD 9600
19200
38400
300
600
1200
2400
4800
BITS 8NONE
7EVEN
7ODD
TERMIN CR/LF
CR
EOLDLY 000
number
ECHO ON
OFF
18 Tracer AV Installation Manual
Specifies settings for baud rate, data bits, termination characters, end-of-line delay, and echo
used by the EDP port.
EDP Port and Printer Port
Baud rate. Selects the transmission speed for the EDP or printer port.
Selects number of data bits and parity of data transmitted from the EDP or printer port.
Termination character. Selects termination character for data sent from the EDP or printer port.
End-of-line delay. Sets the delay period, in 0.1-second intervals, from when a formatted line is
terminated to the beginning of the next formatted serial output. Value specified must be in the
range 0-255, in tenths of a second (10 = 1 second).
NOTE: An EOL may be required for continuous transmission at slower baud rates to
ensure the receiving buffer is empty before another string is transmitted
This command enables or disables echoing of the serial commands sent to the indicator.
Table 3-7. Serial Menu Parameters
Description
